POST TOP
5
ALL VARIANTS
7
10
6
5
8
3a WIRING - BASIC
Max. 2 x 2.5mm²
V/Hz=
i
1.5mm² max.
If ferrulled
(1.5mm² - 2.5mm² cable only)
THROUGH WIRING
11
N
Green & Yellow -
Grün & Gelb
Brown -
Braun
L
9
Blue -
Blau
12
Connect to terminal block
as per Diagram 3a
21LFT72719 - Issue 1 - Rev 0
May 2023
