Data Sheet B.Beat PRO16 Data Sheet B.Beat PRO16
Internal Audio File Format PCM (uncompressed) 48 kHz 24 bit
Compatible audio formats
WAV 44.1 kHz, 48 kHz, 96 kHz 16/14 bit
when importing
MP3 fixed bit rate [64 - 320] kbps
(which will be converted
MP3 VBR
to the internal format)
OGG fixed bit rate [64 - 320] kbps
AAC
STEMS
MTA M-Live
Internal Video Format H-264 HD / Full HD (1280 x 720 / 1920 x 1080)
Compatible Video Formats
MP4,MOV
during import
Compatible image formats JPG, PNG
Video resolution for lyrics
1280 x 720
Digital processing 16 D/A channels 24 Bit Sigma/Delta 48 kHz.
Internal audio outputs Typical S/N ratio 112 dB
Input - 12 Line Jack 6.35 mm mono inputs, unbalanced
- Impedance 10 kΩ
- Range 18dBu, 6 Vrms
- Typical THD+N -93 dB
- Typical SNR 107 dB
Digital processing Internal audio
12 channels D/A 24 Bit Sigma/Delta 48 kHz.
inputs
Typical S/N ratio 112 dB
- 16 Audio outputs Jack 6.35 mm mono, balanced
Output
- Range 10dBu, 2.5 Vrms
- Range 20dBu, 5 Vrms (balanced)
- Typical THD+N -94 dB
- Typical SNR 112 dB
Display
2. 4 " OLED, 128x64, Monochrome
- Stereo Jack 6.35 mm output
Jack Headphone Output
- Typical SNR 105 dB
- Range 6dBu, 1.5 Vrms
Internal memory 128GB, 1TB depending on version
Network Interface RJ45 10/100/1000 Mbps Ethernet socket
6
Data Sheet B.Beat PRO16 Data Sheet B.Beat PRO16
MIDI port MIDI OUT DIN 5-pole standard
MIDI IN via USB-MIDI cable (optional)
Pedal Switch Pedal N/O or N/C, Jack 6.35mm
Power supply 12VDC, 2A, max. consumption 19W
Video 2x HDMI Type A output
Maximum resolution 1920x1080 with video
USB ports 2x USB 2.0 Hi-Speed Type A per Memory Stick,
WiFi USB interface. Max. total current delivered for
the two ports: 500mA
External power supply unit AC/DC Adapter Mod. 13/90288-00 INPUT 100-
240VAC Freq 50-60Hz OUTPUT 12VDC - 2A
Input - 12 Ingressi Line Jack 6.35 mm mono, non bilanciati
- Impedenza 10 kΩ
- Range 18dBu, 6 Vrms
- THD+N tipico -93 dB
- SNR tipico 107 dB
