MAILA DB EXT
®
SPEAKER POLE EXTENSION FOR MAILA DB
SAFETY INFORMATION
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Use the equipment only in the intended manner and for the intended purpose.
5. Do not open or modify this equipment.
DANGER OF SUFFOCATION! KEEP AWAY FROM CHILDREN! THE PRODUCT CONTAINS SMALL PARTS
THAT CAN BE SWALLOWED AND PACKAGING MATERIAL THAT CAN BE SWALLOWED! PLASTIC BAGS
MUST BE KEPT OUT OF REACH OF CHILDREN!
DISPOSAL
PACKAGING:
1. Packaging can be disposed of via the usual waste disposal channels.
2. Please separate the packaging according to the waste disposal and
materials regulations in your country.
DEVICE:
Follow the disposal laws in your country.
MANUFACTURER´S DECLARATIONS
MANUFACTURER'S WARRANTY & LIMITATION OF LIABILITY
Adam Hall GmbH, Adam-Hall-Str. 1, D-61267 Neu Anspach / Email: Info@adamhall.com /
+49 (0)6081 9419-0.
Our current warranty conditions and limitation of liability can be found at:
https://cdn-shop.adamhall.com/media/pdf/MANUFACTURERS-DECLARATIONS_LD_SYSTEMS.pdf.
In case of service, please contact your sales partner.
CE CONFORMITY
Adam Hall GmbH hereby declares that this product complies with the following directive
(if applicable):
Low Voltage Directive (2014/35/EU)
EMC Directive (2014/30/EU)
RoHS (2011/65/EU) RED (2014/53/EU)
SIMPLIFIED UK DECLARATION OF CONFORMITY
Hereby, Adam Hall Ltd. declares that the radio equipment type ( Radio Equip-
ment Regulations 2017) is in compliance with Directive SI2017/1206. The full
text of the UK declaration of conformity is available at the following internet address:
www.adamhall.com/compliance/
CE DECLARATION OF CONFORMITY
Declarations of conformity for products subject to the LVD, EMC, RoHS Directives can be
requested from info@adamhall.com.
Declarations of conformity for products subject to the RED Directive can be requested from
www.adamhall.com/compliance/
Printing errors and mistakes, as well as technical or other changes are reserved!
A
B
LD Systems is a registered brand of the Adam Hall Group
®
Adam Hall GmbH | Adam-Hall-Str. 1 | 61267 Neu-Anspach | Germany | Phone: +49 6081 9419-0 | adamhall.com
PRODUCT INFORMATION
This item is a product-specific system component intended exclusively for use together
with the LD MAILA DB Speaker pole and the GTWB431B Square Steel Touring Base.
These assembly instructions do not replace the operating instructions of the
associated products.
Always read the corresponding operating instructions first.
These accessories have no influence on the intended use of the associated product.
Observe the safety instructions in the operating instructions of the associated product!
The technical data stated in the operating instructions may change in connection with
this item.
SCOPE OF DELIVERY
Remove the product from the packaging and remove all packaging material.
Please check that the delivery is complete and intact and please notify your sales partner
immediately after purchase if the delivery is not complete or damaged.
The packaging content of the product includes:
• 1x Speaker pole extension LD MAILA DB EXT
• Assembly instructions
ASSEMBLY
Guide the speaker pole with the M20 threaded bolt
element in the Square Steel Touring Base (GTWB431B) and screw the bolt clockwise into the
B
M20 thread as far as it will go.
Screw the Speaker pole for MAILA SPA (MAILA DB) with the M20 threaded bolt
D
M20 thread of the rod extension (MAILA DB EXT) as far as it will go.
Now insert the amplifier module (MAILA SPA)
in the desired direction of radiation. Unintentional twisting of the amplifier module is
prevented by a tongue and groove principle.
SPECIFICATIONS
Item number LDMAILADBEXT
Typ MAILA Pole
Tubing material Steel
Tubing colour Black
Tubing surface Powder coated
Height 500 mm
Lower connector M20
Weight 1.58 kg
C
D
A
first vertically to the connecting
C
into the
E F
from above onto the speaker pole
E
F
