Also, the following panel events are transmitted to the keyfob,
and indicated by the keyfob's LED state:
System status
System disarmed
System armed (away and stay)
System in alarm (intrusion event,
life safety)
System trouble (can't arm)
Keyfob low battery
In case the user is out-of-range of the receiver, this will be
indicated with the LED flashing yellow 2 times.
The keyfob will send a low battery signal when the battery
voltage goes below 2.2 V and it will also be reported to the
panel if the keyfob is learned into the panel.
Keyfob is able to signal low battery for at least 30 days,
assuming that the system is armed and disarmed once a day.
Stay mode options
Single press of the button
active – interior zones are bypassed.
If you press the button again, Stay Instant mode activates −
your entry/exit delay zones will not be bypassed anymore and
will become instant.
If you press the button a third time, Stay Night mode activates
− in addition to entry/exit zones, also zones set up as "night
zones" will become instant. This prevents even authorized
users from entering the protected area unless it is disarmed
first (for example by someone inside the Stay area).

Replacing the Battery

Because keyfobs are non-supervised devices, a low battery
signal will only be received by the control panel when the
device is within range of the receiver and a button is pressed (if
the device is not in use, no low battery signal will be sent until
a button is pressed). When the device is carried beyond the
range of the receiver and/or is seldom used/tested, the battery
could wholly deplete without a warning of the battery condition
being sent to the panel. If the LED on the device appears dim
or does not turn on when a button is pressed, it is a warning
that the battery may be low or depleted and should be
replaced. To ensure proper functionality, test the device weekly
and follow these simple steps to replace the battery when
necessary:
1. With a key or small screwdriver, press the black tab
located at the bottom of the remote (Figure 1) and slide
the chrome trim off.
2. Carefully separate the front and back piece of plastic to
reveal the battery.
3. Replace with a CR2032 battery ensuring the + side of the
battery faces up (Figure 2).
4. Re-assemble the plastics and ensure they click together.
5. Ensure the notch in the chrome trim is aligned with the
back of the plastic. It will only go on one way (Figure 3).
2 / 18
LED indication
Green flashing LED for 1 second.
Red flashing LED for 1 second.
LED alternates flashes between
red and green 2 times, then stays
red for 3 seconds indicating an
alarm condition.
LED flashes yellow for 1 second.
LED flashes yellow 3 times.
makes the normal Stay mode
Specifications
Compatibility
Wireless operating frequency
Power output
Quiescent current
Battery
Battery Life
Weight
Gross weight with packaging
Packaging dimensions
Power supply type
Housing
Operating environment
Temperature
Relative humidity

Regulatory information

PLACED ON THE MARKET BY:
Manufacturer
Carrier Fire & Security Americas Corporation Inc.
13995 Pasteur Blvd
Palm Beach Gardens, FL 33418, USA
AUTHORIZED EU REPRESENTATIVE:
Carrier Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings THESE PRODUCTS ARE INTENDED FOR SALE
and disclaimers TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. CARRIER FIRE &
SECURITY CANNOT PROVIDE ANY
ASSURANCE THAT ANY PERSON OR ENTITY
BUYING ITS PRODUCTS, INCLUDING ANY
"AUTHORIZED DEALER" OR "AUTHORIZED
RESELLER", IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL FIRE
AND SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/
Certification
EN 50131-3:2009
Environmental Class II
Security Grade 2
Tested and certified by Telefication B.V.
Carrier Fire & Security hereby declares that this
European Union
device is in compliance with the applicable
directives
requirements and provisions of all applicable rules
and regulations, including but not limited to the
Directive 2014/53/EU. For more information see:
https://www.firesecurityproducts.com
Product may contain substances that are also
REACH
Candidate List substances in a concentration
above 0.1% w/w, per the most recently published
Candidate List found at ECHA Web site.
Safe use information can be found at
https://firesecurityproducts.com/en/content/intrusi
on-intro
Aritech LoNa transceivers (e.g.
ZeroWire)
433.65 MHz
−9 dBm EIRP
0.5 µA
3V lithium CR2032 (210 mAh)
5 years
42.5 g
45.3 g
41 x 21 x 67 mm
EN 50131-6:2017 Type C
EN 50131-3:2009 ACE Type B,
portable
0 to +45°C (+32 to113°F)
5 to 95% noncondensing
or scan the QR code.
P/N 422-5828 • REV P • ISS 15DEC20
