ASRV3 + ASRV3
(SRV2-S + SRV2-S)
C
TYP A
ASRV3 75 + ASRV3 75 720 - 740
ASRV3 80 + ASRV3 80 770 - 790
ASRV3 90 + ASRV3 90 870 - 890
ASRV3 100 + ASRV3 100 970 - 990
ASRV3 75 + ASRV3 90 720 - 740
SRV2-S 75 + SRV2-S 75 720 - 740
SRV2-S 80 + SRV2-S 80 770 - 790
SRV2-S 100 + SRV2-S 100 870 - 890
SRV2-S 75 + SRV2-S 75 970 - 990
SRV2-S 75 + SRV2-S 90 720 - 740
ø 8
ø 2,8
B C D
720 - 740 495
770 - 790 543 800
870 - 890 635 900
970 - 990 670 1000
870 - 890 570
720 - 740 396
770 - 790 431 800
870 - 890 504 900
970 - 990 530 1000
870 - 890 454
D
V
1880
1880
1880
1880
1880
1850
1850
1850
1850
1850
1
