Anschlüsse
- Connections
Anschlüsse Pult:
Connections in the lectern
1
Shockmount-Halterung mit XLR für
Schwanenhalsmikrofon
2
3 x USB 3.0-Anschluss (aktiv)
z. B. für USB-Datenstick, USB-Leseleuchte
mit Schwanenhals
1
Shockmount holder with XLR for swan neck
microphone
2
3 x USB 3.0 connection (active)
e.g. for USB stick, USB reading light with swan
neck
Anschlüsse Säule:
Connections in the column:
230 V-Anschluss, z. B. für Laptop
4
USB 3.0 (aktiv)
5
Audio-Klinke 3,5 mm
6
HDMI-Buchse
7
VGA-Buchse
8
Netzwerk (Cat-6, RJ45)
9
230 V connection, e.g. for laptop
4
USB 3.0 (active)
5
Audio jack 3.5 mm
6
HDMI socket
7
VGA socket
8
Network (Cat-6, RJ45)
9
Die Anschlüsse in der Säule sind direkt mit den entsprechenden Anschlüssen im Sockel
verbunden.
The connections in the column are directly connected with the corresponding connections in
the base.
