Accessories

Circuit Meeting Room requires a web camera and a speaker phone.
products, such as Jabra Speak 410 speaker phone and Logitech C925e webcam, should be used.
For additional compatible products please visit
Circuit_Meeting_Room
.
G

Connectors and Buttons

Front panel of the FUJITSU ESPRIMO Q957
Rear panel of the FUJITSU ESPRIMO Q957
3
1
USB 3.0 connectors
2 Power button
3 Power cable connector
4a DisplayPort connector for primary
display

Getting Started

1 Connect the web camera
Plugin the USB cable of the
web camera H to an avail-
able USB connector 6 .
3 Connect the network cable
Connect a network cable to
the network connector 5 .
5 Connect the power cable
3
B
Connect the power cable
to the power cable connector
3
.
1 For a dual display configuration, connect the primary display to DisplayPort connector
2 For displays with HDMI connector(s), please use a DisplayPort to HDMI adapter or cable.
3 Check whether the local mains voltage corresponds with the indications on the label of the de-
vice, before plugging the other end of the power cable into a power outlet.
4
wiki.unify.com/wiki/
G
Speaker phone Jabra Speak 410,
packaged together with its Getting
Started, Warranty and Safety/ Regu-
lations documents
H
Web camera Logitech C925e, pack-
aged together with its Setup Guide,
and Important Information, Safety,
H
Regulatory and Warranty docu-
ments
1
2
4 5 6 1
4b
4a
4b
DisplayPort connector for second-
ary display
5 Network connector
6 USB 2.0 connectors
2 Connect the speaker phone
Plugin the USB cable of the
speaker phone
available USB connector
4 Connect the display
Connect the display to a Dis-
playPort connector
turn the display on.
6 Turn on your Circuit Meeting
Room
Press the power button
the Circuit Meeting Room.
Only compatible
G to an
6 .
1
2
4 and
2
of
4a
.
