Operation

How to operate the TFT drawer:
1. Use the handle to pull the drawer out of the rack.
2. Lift the display to activate it.
3. If necessary, press the device's
4. Set any resolution up to
NOTE: When using both video inputs (DVI and VGA), press the
to switch between digital and analogue input.
Press the button for auto adjusting the analogue signal.
Auto
5. After operation close the display, and slide the drawer back into the rack.
Power button (see image 6 on page 3).
1280 × 1024 @ 60 Hz .
Operation
Source button
G&D RackConsole 17 · 4
