2. Delivery / Scope of delivery
After receipt of the goods please check whether the delivery is complete and whether the items are intact.
The delivery consists of one reel AQUALUC C:URVE mini including a connection cable.
3. Area of application
Examples for applications of the AQUALUC C:URVE mini:
• accent illumination
• architectural illumination
• shipbuilding
• stairway illumination
4. Technical data [extract]
Detailed technical information can be found in the relevant data sheet at www.barthelme.de
5. Installation and commissioning
5.1 Installation and processing guidelines
• The processing temperature range of the AQUALUC C:URVE mini is between 15°C and 35°C. Tempe-
ratures below this can negatively influence the flexibility of the stripe and can result in damage. If the
AQUALUC C:URVE mini was previously exposed to lower or higher temperatures, then it must be slowly
brought into the processing temperature range.
• Please note that the AQUALUC C:URVE mini can marginally expand or contract with changes in tempera-
ture at the installation location. This is not a defect in the product but a normal physical process. Speci-
fically, this means that there is a linear thermal expansion of approx. 1 mm per meter and 15 °C change
in temperature. This extra expansion gap should always be taken into consideration prior to installation.
• To avoid damaging the AQUALUC C:URVE mini, especially during unrolling or mounting, it is important
that two people install the product. This is especially valid for a length of one meter (1 m) or more. Care
should be taken that the product does not sag otherwise irrevocable damage can occur (see illustration
1). Furthermore, the encapsulation of the product may not be damaged otherwise a sufficient protection
of the LED stripe cannot be ensured. It is important to never exceed the minimum bending radius!
• The minimum bending radius of the AQUALUC C:URVE mini is 5 cm. The minimum bending radius
may not be exceeded and the stripe may not be bent, otherwise the AQUALUC C:URVE mini could be
damaged (see illustration 2).
• The product is suitable for installation on the floor, wall or ceiling - indoors and outdoors. Make sure that the
product is mounted on a clean, flat and stable surface.
• illumination for outdoor, wellness, spa and pool areas
• backlight for illumination of letters
• exhibition lighting
• illumination for bars, and many more
AQUALUC C:URVE mini
24 V DC
Outdoor IP67/68
60.5 W
2,700 K | 3,000 K | 4,000 K | 5,700 K
8 mm
7,580 mm
6 x 13.5 mm
operating voltage
protection class
Typ. power
colour temperatures
LED pitch
dimension length
dimension
width x height
