PowerLine HD Ethernet Adapter • Quick Install Guide
thank you for purchasing the intEllinEt nEtWoRK solutions
adapter, Model 503273.
this guide presents the basic steps to set up and operate this device. For detailed
instructions and specifications, refer to the user manual on the cD enclosed with this
product or at www.intellinet-network.com.
hardware installation
to connect the existing ac wiring in your home or office to the Ethernet network, this
device can be attached to a lan switch; however, each pc or server plugged into an
ac outlet needs to be directly attached to its own powerline adapter.
1. using the included Ethernet cable, connect the adapter to the computer.
2. plug the adapter into an ac outlet. IMPORTANT: Because the adapter sends data
over home or office ac power lines, plug it directly into an lectrical outlet — not a
universal power supply or power strip with surge protection. the adapter has its
own power filter for protection against surges.
Using a Router
to connect the adapter to a router, disconnect the network cable from the pc and
connect it to the uplink port of the router. if only a lan port is available on the router,
use a crossover cable to connect the adapter to the router.
lED status
power on
off
link/act on
Blinking
off
Ethernet on
Blinking
off
configuration utility
after installing the adapter, run the setup Wizard to install the powerpacket con-
figuration utility. use this utility to check the pc's direct connection to the ac power
network, to search for powerline devices on your network, and to set up security
using a network password. NOTE: if you want the devices on your powerline network
to share high-speed internet access, connect the adapter to a router after you run the
powerpacket configuration utility (see above).
2
English
DEscRiption
power on
power off
ac power line port detects another powerline device
looking for more powerline devices
ac power line port is not detecting another powerline device
Ethernet port link
Ethernet activity
no Ethernet port link
English
powerline hD Ethernet
™
