1. Control panel

2. Top cover
3. Swing leaf
4. Front housing
5. Rear housing
6. Caster wheels
7. EVA filter housing
8. Handle
9. Air vent
10. Continuous drainage hole
11. CON filter housing
12. Drainage hole
13. Mains power cable
14. Power plug
15. Adjustable slider bar
16. Slide bar connector
17. Exhaust pipe
18. Exhaust pipe joint
19. Remote control
15
1 2
E NGL I SH
8

PARTS LIST

16
CONTROL PANEL
3 4
1. Swing
2. Timer
3. Fan Speed
4. Up
5. Display window
1
2
3
4
5
6
7
8
9
10
11
12
13
14
17
5 6 7
6. Down
7. Mode selection
8. Sleep mode
9. Power
10. Water tank full light indicator
11. WiFi
18 19
8 9 10 11
