Using the cleaning cloth holder and squeegee head.
Assembly:
1. Take a cleaning cloth and attach it to the cleaning cloth Velcro holder.
2. Connect the cleaning cloth holder to the puller head along the lower central guide rails of the
puller head.
Disassembly:
Press the locking button to extend and retract the cleaning cloth holder and push it forward to extend
it.
Using the squeegee head, cleaning cloth holder and housing.
Assembly:
Press and hold the cleaning cloth holder latch and connect it to the housing.
Disassembly:
Press and hold the latch of the cleaning cloth holder and pull it out in the opposite direction.
Mount the extractor head:
Put the puller head on the top
opening of the unit.
Dismantle the extractor head:
Press the locking button of the
extractor head and remove it.
Mount the water tank:
Push the water tank upwards along the guide grooves in the
appliance until it locks into place.
Dismantle the water tank:
Press the white latch under the water tank outwards to then
remove the water tank.
Mounting the cleaning cloth holder:
Press the locking button of the cleaning cloth
holder and slide it onto the guide groove
provided for it.
Dismantling the cleaning cloth holder:
Press the locking button, lift the cleaning cloth
holder slightly at the back and slide it out
towards the front.
