PRODUCT OVERVIEW

MICROPHONE
1 Microphone Capsule Area
2 Rear Venting Area
3 Shock Mount
4 Thumb Screw
5 XLR Port
6 Microphone Stand
1
6
2
3
4
5
6
STREAM MIXER
7 RGB Level Indicator Ring
8 Microphone Gain Dial
9 Programmable Volume Dial (default Headphone)
10 Microphone Mute Button
11 Programmable Mute Button (default Headphone)
12 +48V Phantom Power LED
13 XLR Port
14 USB-C Port 1
15 USB-C Port 2
16 Line Out (Please install GG/Sonar software to access this feature)
17 Power Button
18 Power Cable Port
19 3.5 mm Headphone Port
20 RGB Ambient Base Light
8
7
10
12 13 16
LINE OUT
14 15
9
11
17
18
19 20
7
