Specifications - Ruark Audio R1 Bedienungsanleitung

18
19 20 21 22 23
18. Aerial
Removable telescopic with F-Type connector
19. Program port
For factory and dealer use only
20. 14VDC 1.5A
Adapter connector
21. 3.5mm headphone socket
22. Line out - 3.5mm jack
Connect to amplifier or recording device
23. Line in - 3.5mm jack
Connect an external source e.g. MP3 player
24. Ambient light sensor
Automatically adjusts screen brightness to suit
ambient conditions.
IMPORTANT: To ensure correct function do
not cover the sensor.
24

Specifications

R1 Tabletop Radio
●
DAB / DAB+ / FM with RDS
●
3.5mm headphone output
●
Aux line input - 3.5mm stereo jack
●
Line output - 3.5mm stereo jack
● 3.5" loudspeaker in tuned bass reflex
cabinet
●
9w nominal power output
●
Aerial: Removable telescopic with
F-Type connector
●
High contrast, backlit LCD with auto
dimming
●
Large format clock display
●
2 x 16 character area for station names
/ info etc
●
Dimensions: 175x130x135mm
(6.9x5.1x5.3ins)
●
Weight: 1.5 kg (3.3 lbs)
Power supply
●
Input power 90V to 240VAC 50-60Hz
0.5A
●
Output power 14VDC 1.5A
