GRAVITY GLS431B Bedienungsanleitung

GLS431B
Lighting Stand with Square Steel Base
(prepared for off-centre weight attachment)
SAFETY INFORMATION
1. Please read these instructions carefully before you start installation and
assembly.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other infor-
mation from the equipment.
5. Be attentive when setting up the product and protect yourself from injury.
6. This product is intended for indoor use only. Using it outdoors could lead to
product failure and personal injury.
7. Do not modify this equipment.
8. Comply with all applicable disposal laws in your country. During disposal
of packaging, please separate plastic and paper/cardboard.
9. Plastic bags must be kept out of reach of children.
10. If you have any questions refering to this instruction or any warnings,
please contact your local distributor.
MANUFACTURER'S WARRANTY & LIMITATION OF LIABILITY
You can find our current warranty conditions and limitation of liability at:
http://www.adamhall.com/media/shop/downloads/documents/manufac-
turersdeclarations.pdf
To request warranty service for a product, please contact Adam Hall GmbH,
Daimler Straße 9, 61267 Neu Anspach / Email Info@adamhall.com /
49 (0) 6081 / 9419-0
PROPER DISPOSAL OF THIS PRODUCT
(WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)
(Valid in the European Union and other European countries with waste
separation)
This symbol on the product, or the documents accompanying the product, indi-
cates that this appliance may not be treated as household waste. This is to avoid
environmental damage or personal injury due to uncontrolled waste disposal.
Please dispose of this product separately from other waste and have it recycled
to promote sustainable economic activity.
INTRODUCTION
The GLS 431 B lighting stand features a large heavy steel base providing a
firm footing and three M20 female threads that allow to mount extra weights
off-centre. The 35 mm extension with female threaded M10 insert permits a
maximum height of 2.4 m. Two integrated base handles facilitate transport.
FEATURES
• Large heavy steel base for stability
• Base with 3 M20 female threads for off-centre weight mounting
• 35 mm extension with M10 female thread
• 2.4 m maximum height
SPECIFICATIONS
Adam Hall GmbH · Daimlerstr. 9 · 61267 Neu-Anspach · Germany
Tel.: (+49) 60 81 / 94 19 0 · Fax: (+49) 60 81 / 94 19 1000 · eMail: mail@adamhall.com
Product type:
Type Lighting:
Tube material:
Tubing colour:
Tubing surface:
Min height:
Max height:
Transport length:
Height adjustment:
Number of extensions:
Base material:
Material of height adjustment:
Tube diameter:
Dimensions Base (W x H x D):
Base weight:
Interchangeable rings:
Black ring pack included:
Max. load capacity:
Weight:
stands and Tripods
stands
steel
black
powder coated
1420 mm
2420 mm
1420 mm
set screw and safety pin
1
steel
steel
35 mm, M10 threaded
563 x 563 x 15 mm
14 kg
yes
yes
20 kg
17,8 kg
