4.

FIELD-PROGRAMMABLE SETTINGS

DISPLAY
The solenoid coil's actual current is displayed in Ampere units during regular operation.
Other displays:
Hnd indicates that the Manual mode has been selected.
Err Internal overflow.
AEr Autozero overflow.
AdA Auto-adapt is active.
PUSHBUTTONS
To enter the Manual mode, press and hold both pushbuttons simultaneously during power up. "Hnd" appears in the display.
Use the UP button to increase the coil current and the DOWN button to decrease it. The actual coil current is displayed.
Quick presses on the buttons allow you to make slight changes in the current setting.
Longer presses allow you to make quick changes to the current setting.
Press both pushbuttons simultaneously to exit the manual mode.
5.

TECHNICAL CHARACTERISTICS

5.1

GENERAL

Ambient temperature
5.2

CONSTRUCTION

Body
Protection
Electrical connection
Mounting
5.3

ELECTRICAL CHARACTERISTICS

Supply voltage
Max. current of
proportional solenoid valve
Setpoint input
Sensor input
Feedback output
Ramp
Adjustable switching frequency
6.

ACCESSORIES

Description
"ASCO-DigiCom" C
ONTROL
USB cable for C to PC connection (to be ordered separately)
D
ONTROL
DP-IM14152-8
-20 °C to +50 °C
PA (Polyamid)
IP20
pluggable terminal block (0,08 - 1,5 mm²)
DIN-EN 50022 rail
(U ) 24 V DC ±10 %, max. ripple 10 %
N
or 12 V DC +15 % -5 %, max. ripple 10 %
2 A
0 - 10 V DC, 0 - 20 mA, 4 - 20 mA
0 - 10 V DC, 0 - 20 mA, 4 - 20 mA
0 - 10 V, 0 / 4 - 20 mA
ON/OFF, adjustable between 0,1 and 20 seconds
20 to 2000 Hz
software on CD-ROM (supplied with the controller)
D
INSTALLATION
catalogue no.
88100893
88100894
