MF Control

3 Product description

3.1 Technical data
Dimensions (lxwxh)
Weight
Connection cable length
Supply voltage
Current consumption
Protection type of panel front
Protection type of housing
Display
CPU
Mass storage
RAM
Ethernet
USB 2.0
Operating system
Tab. 1
Ambient temperature
Tab. 2

3.2 Nameplate

The MF Control is labelled with a nameplate on the back of the housing as follows:
Fig. 1
When making enquiries, please note the following information:
• Type, serial number
MF Control remote control
Ambient conditions during operation
Nameplate
3 Product description
270 × 247 × 90 mm
2.0 kg
10 m
24 VDC via the connection lead
650 mA
IP 65
IP 54
7-inch TFT with resistive touchscreen,
WVGA 800 × 480 pixels
Intel Atom 1.0 GHz E640T
16 GB SATA SSD
1 GB DDR2
1× via the connection lead, 1× on top of housing
1× on top of housing
Microsoft Windows® Embedded Standard 7
−20 °C to +70 °C
EN - 5
