Ritzel-, Motorbefestigung Pinion-, Motor Mount; Benötigtes Zubehör - Buri-Racer E2 Bauanleitung
Inhaltsverzeichnis
103c
103b
103c
553
553
443-08
101
103a
445-12
445-12
445-12
optionale Karosseriesteher
(nicht im Baukasten enthalten)
optinal body mount
(not included in this kit)
Nr.
Benennung
name
Stk/pcs
103a
Rammschutz
bumper
1
103b
vordere
front plastic
1
Karosserie-
body support
brücke
103c
Karosserie-
plastic body
2
steher
tower
440
Sicherungs-
lock nut
1 / 3
mutter M4
444-08 Schraube ISK
button head
2
M4x08 FL
screw flanged
445-12 Senkschraube
flathead screw
3
ISK M4x12
Alternative Positionierung
alternative position of body mounts
444-08
440
22103 Rammschutz
bumper
1
22108 Carbon
front carbon body
1
Karosseriebrücke
support
22115 Karosseriesteher
body tower
2
434-06 Schraube ISK
button head
2
M3x06 FL
screw flanged
440
Sicherungs-
lock nut
1
mutter M4
444-06 Schraube ISK
button head
2
M4x06 FL
screw flanged
445-10 Senkschraube ISK
flathead screw
3
M4x10
463-10 Distanz M4x10
distance nut
2
553
Karosserieclips
body mount clips
2
553
22115
444-06
initial position
444-06
22115
553
22108
434-06
463-10
434-06
463-10
22103
22101
445-10
445-10
445-10
Fertigstellung
finalisation
2x 13220 fan mount
2x 433-10 button head screw
motor cooling fan 30 or 40mm
4x 433-16 button head screw
21217small/13217medium/12217large
Ritzel-, Motorbefestigung
pinion-, motor mount
10204-14 Ritzel z14
446-04
Gewindestift M4x4
434-06
Schraube ISK M3x06 FL button head screw flange 4
444-06
Schraube ISK M4x06 FL button head screw flange
alternative
440
444-06
benötigtes Zubehör
final assembly – additional equipment
receiver
Empfänger
transponder Transponder
f tire
Vorderrad 69mm
r tire
Hinterrad 71mm
motor
Motor 4268
controller
Regler
2s LiPo
LiPo Stic or Shorty 2s, minimum 6000 mAh, >80c
airscoop
3x 433-06 button head screw
receiver housing
antenna tube
22217 receiver housing
rear / front position
pinion t14
1
setscrew
1
2
434-06
434-06
444-06
434-06
434-06
446-04
10204-14
446-04
10204-14
(nicht im Baukasten enthalten)
(not included in this kit)
receiver
1
transponder
1
front wheel
2
rear wheel
2
1700 to 2200kv, max. lenght 69mm 1
speed controller, max 40x56mm
1
2
