Instructions for castors, base and screwable base
Here you can find the EU-declaration of conformity: www.thermotec.ag/konformitaetserklaerung/
CAUTION - Warning
Acute risk of falling: The castors, the base and the
screwable base must not be used with the following
products:
AeroFlow®
SLIM TALL 1600
Installation screwable base:
You need 2 persons for mounting.
WARNING: Do not drill in wooden floors or if underfloor
heating is installed. Check the underground for power cables
and piping.
DANGER: Make sure that the surface is level. On inclined
floors, the radiator is slanted and can easily tip over.
1. Insert the base from below into the radiator and move the
radiator in its final position.
2. Draw three holes each on the concrete floor for the right
and le base. The floor must be level.
3. Lay the radiator on its side so that the temperature sensor
underneath is not damaged.
4. Now drill the holes (Ø 12 mm) and insert the dowels.
Depending on the type and condition of the floor, suitable
screws and dowels should be used.
5. Put the heater back in place.
6. Screw the base firmly onto the concrete floor.
7. Check the heater for a secure hold. Finished!
Drill pattern for
screwable base
Disposal of equipment packaging
The packaging is used to protect the equipment from damage during transport. All packaging materials should be disposed of in accordance with the applicable legal regulations.
For more information, contact the local authorities.
The packaging material used is environmentally friendly and suitable for reuse or recycling. The corrugated board used reaches a recycling rate of almost 100%. The transparent
protective films are made of completely harmless and food safe polyethylene (LDPE), the lashing straps are made of polypropylene (PP) and the covers are made of polyethylene
polymers (PE_PR). These materials form pure hydrocarbon compounds and are recyclable. By recycling or reusing packaging materials, the consumption of raw materials and the
amount of residues and waste can be reduced.
Caution: Packaging materials are not toys. Do not let children play with them. Risk of suffocation by films and folding cartons.
When using this driving base for electric heating appliances, Directive 2009/125/EC states that electric portable local space heaters are only suitable for well insulated
spaces or for occasional use.
Thermotec AG | Arnsdorf 26 | 02894 Vierkirchen | Deutschland
Towel Rail Type DHH
46
Telefon: +49(0)3 58 27 78 93 30
E-Mail: info@thermotec-ag.de
Installation castors and base:
1. Unpack your electric radiator and lie it flat on the floor
with the ribs facing you.
2. Take the base/castors and insert them into the second
rib opening from the left and right.
3. Stand up the electric radiator horizontally and connect it
to the plug socket. Done!
Model Dim. X
MINI 650
133 mm
COMPACT 1300
433 mm
MIDI 1950 733 mm
MAXI 2450 1033 mm
Dimension X
Registergericht: Amtsgericht Dresden, HRB 33568
USt-Id.-Nummer: DE 251 965 324
Clearances
Model Dim. X
SLIM 1200
733 mm
SLIM 1600
1033 mm
SLIM 2000 1333 mm
