7 Installation
Always install the instant water heater on the water connection before plugging it into the
grounded socket. Follow the reverse order to disassemble.
The device comes with three different connection adaptors that fit the most popular water
connections. Use the adapter that fits your connection.
Always use the supplied precision-fit silicone O-ring for each adapter. Ensure that
the screw connections are secure and tight.
The instant water heater should only be installed in a vertical position! The water
outlet must always face downwards.
Use the thread adapter that fits your connection:
M22 -> G3/4" M22 -> G1/2"
3x
Connection examples:
Connection to a water tap with male thread
Universal connection (hose connection) with clamp ring
Connection to a water tap with female thread (optional)
Matching thread adapters for taps with female thread are available at specialist shops. The
instant water heater connection has an M22 female thread.
-> G1/2"
M30 -> G3/4"
8 Operation
The instant water heater features integrated dry-run protection. The heater only kicks in when
water flows through the device and the hot mode has been set.
Use the controller (4) on the side to adjust the flow rate and water temperature. The heating
power depends on the flow rate. When in the middle position, the flow rate is limited by a spray
jet at the outlet. This position provides the hottest water. Setting the controller to the red area
(HOT) increases the flow rate but reduces the water temperature.
Setting the controller to the black area (COLD) shuts the heater off. Turning the controller
further into the black area (COLD) increases the flow rate. Water temperature is not displayed
in the cold water range.
Turning the controller to either of the two end positions produces an audible click to indicate
the maximum flow rate.
When you close the water tap, the instant water heater switches off automatically. When in hot
mode, the temperature display turns off.
9 Troubleshooting
Error Cause
Temperature display is blank No power supply
No water flow
Controller set to cold mode
Water is not hot enough The flow rate is too high.
Water is too hot The water inlet is blocked.
The water flow is low.
The heater will not kick in. The water flow is too low.
Inconsistent water stream The bead nozzle at the out-
from a faucet. let is soiled.
The heater does not work, The internal circuit breaker
but the temperature is dis- or overload/overtemperature
played. protection has tripped.
Resetting the temperature and overload protection (Reset)
If the instant water heater stops working, check whether the internal circuit breaker has tripped.
The reset button is concealed. Before resetting, unplug the device from the power outlet.
Pull the cap on the controller gently to the side of the device to access the reset button. Push
the reset button until it clicks. You may need a suitable screwdriver to do this.
Replace the cap and plug the device back into the power outlet. The instant water heater should
now work again.
Reset
If the instant water heater will not start, disconnect it and contact customer service.

10 Cleaning and care

Important:
– Do not use aggressive cleaning agents, rubbing alcohol or other chemical solutions.
They can damage the housing and can cause the product to malfunction.
– Do not immerse the product in water.
1. Disconnect the product from the power supply.
2. Use a damp, lint-free cloth to clean the product.
3. Clean the water inlet and outlet, if necessary. Use a natural limescale remover (e.g. cleaner
with citric acid, etc.). Thoroughly rinse the cleaned parts with clear water.
Remedy
Connect the power plug
Open the water tap
Set the controller to the mid-
dle position or the red area.
Turn the controller to the
middle position.
Check the water inlet and
clean it.
Open the water tap further.
Open the water tap further.
Remove the bead nozzle at
the outlet and clean it (des-
cale).
Reset the instant water
heater.
