HOMCOM 839-145 Montageanleitung Seite 3

PART LIST
6
7
13
13
1
5
4
7
2
3
11
10
x2
12
9
8
A x 8 B x 14 C x 14 D x 24 E x 2 F x 2 G x 2
(6 x 30mm) (6 x 35mm) ( 15 x 10mm) (3.5 x 12mm) (L=30cm) (L=30cm) (L=30cm)
(+1 spare) (+1 spare) (+1 spare) (+1 spare)
H x 2 I x 2 J x 12 K x 1 L x 2 M x 4 N x 14
(L=30cm) (4 x 20mm) (6 x 25mm) (6 x 45mm) (4 x 35mm)
(+1 spare)
