10G Ethernet Media Converter
Quick Install | Snel installeren | Installation rapide | Installazione rapida | Schnelle Installation | Instalación rápida |
Instalação rápida | Gyors telepítés | Rychlá instalace | Hurtig installering | Hurtiginstallasjon | Snabbinstallation |
Pika-asennus | Hitra namestitev | Γρήγορη εγκατάσταση | Бърза инсталация | Szybka instalacja
PWR
10G
Link
Link
ACT
SD
ACT
+
ON
DIP
ON
OFF
ON
DIP
ON
OFF
ON
DIP
ON
OFF
LED Description
LED
Function
Status
On
PWR
Power LED
Off
On
10G Speed
10G
Active
Off
On
Fiber Port (FP)
Link ACT
Link/Action
Blink
Status LED
Off
On
UTP Port (TP)
Link
Link Status
LED
Off
On
Fiber Signal
SD
Status LED
Off
Blink
UTP Port (TP)
ACT
Action Status
LED
Off
DIP Switch 1
ON
LFP function enabled
OFF
LFP function disabled
DIP Switches 1 and 3
ON
Bypass mode enabled
OFF
Bypass mode disabled
Dip Switches 1, 2, 3, 4 OFF
LFP function disabled
Adaptive mode enabled
AC4455
Description
Power is on
Power is off
10Gbps speed
10/100/1000Mbps Speed
Fiber Port is linked
Fiber Port has data
Fiber Port is not linked
UTP Port is linked
UTP Port is not linked
Fiber Signal is detected
Fiber Signal is not detected
UTP Port has data
UTP Port has no data
