Instructions
Connections
• All ports on the switch support Auto-MDI/MDI-X functionality,
so you can use straight or crossover UTP/STP cables to connect
the RJ45 ports to PCs, routers, hubs, other switches, etc.
• Cat5e/6/6a/8.x UTP/STP cables provide optimal performance;
if a status LED doesn't indicate a link or activity, check the
corresponding device for proper setup and operation.
• Use the included power cable to connect the receptacle on the back of the
switch to a power outlet, and confirm that the Power (PWR) LED lights.
LED
PWR
RUN
1–48
Link/PoE*
49S–54S
(SFP+)
* NOTE: Press the CTRL button to alternate between Link or PoE Status.
Basic Web-Based Browser Management
1 Open your Web browser.
2 Enter http:// and the IP address of the switch in the Address
field. The default management IP address is 192.168.2.1.
3 Press Enter to display the login screen. In the Username
field, enter admin; in the Password field, enter the serial
number on the bottom of the switch. Click OK.
Color Status
Blinking
Green
Off
Blinking
Green
On
On
Green
Blinking
Off
On
Green Blinking
Off
Operation
Unit is receiving power.
Check connection.
System is booting.
System has booted successfully.
Valid port connection. /
The connected device (PD)
is receiving power.
Data transmitted/received.
No link established. / No powered
device (PD) is connected to the port.
Valid port connection.
Data transmitted/received.
No link established.
*
