Eurotops 47275 Bedienungsanleitung

EP591N/HT-998
PLEASE READ THE MANUAL BEFORE YOUR FIRST USE. KEEP THIS MANUAL SAFE FOR FUTURE
A. PRODUCT DESCRIPTION
1. LED torch and siren light
2. Solar panel and table lamp
3. Thermometer
4. Strap
5. Turning frequency
6. Power selector switch
7. Volume control
B. TECHNICAL SPECIFICATIONS
1. Frequency Range: AM(MW) 520-1600KHz / FM 87.5-
108MHz / SW 3.0 -17MHz
2. Technical data
Rechargeable battery: Lithium 3.7V 1200mAh
Dry cell: DC 4.5V AA x 3pcs
Solar panel output: 3.8V 55mA
Handle Generator output: 4V 450Ma
Mobile recharging output: 5V 400mA
Micro USB charging cable: 5V/ 2A
3. Thermometer: -20℃- +50℃
4. Power out: 148mW
Battery Pack Charging Time (Solar energy):
Autonomy- Dynamo crank handle:
Type of Solar panel:
Output Voltage:
Energy source
C. USING THE PRODUCT
1. Thermometer: Suitable for -20℃-50℃ Range indication.
2. Using function switch: Put function selector（8）to "FLASHLIGHT" for LED torch, to "SIREN" position for using
emergency siren function and it will change the LED light to a blinking red light. Turn on the "Volume Control"(7) to
turn on or off the siren sound. Open up table lamp (2), turn function Switch (8) to "LIGHT" position to use table lamp.
Note: when you are not using the table lamp, turn the Function Switch to "OFF", it will turn off the siren,
table lamp and flashlight.
3. Power source: press power selection Switch (6) to "RECHARGEABLE BATTERY" position for choosing rechargeable
battery power supply. Press again to use "DRY CELL" for using battery power source.
AM/FM/SW SOLAR DYNAMO RADIO
User Manual
REFERENCE!
8. Function switch output
9. Bands switch
10. Tuning knob
11. Speaker
12. Dynamo crank handle
13. Cell phone charger output
14. Earphone jack
1
15. 5V Micro USB jack
16. Telescopic antenna
17. Battery compartment
5.Speaker: Φ66mm 8Ω 1W
6.External earphone: Φ3.5mm 32Ω X2
7.Dimension: 242x136x73mm
8.Weight: 650g (dry battery not included)
20-24hrs
150mins charge for a fully of the battery
poly-crystalline solar cell, 5v 55mA
5.2V
Solar ,dynamo, Micro USB charging cable, and dry
batteries
English
