exocutor Insect-O-Cutor EX16 Gebrauchsanweisung Seite 2

C AT C H T RAY REMO VAL
T he c a tc h tra y is c o nne c te d to the p o we r sup p ly o f the unit via a hid d e n switc h. By
re mo ving the c a tc h tra y, the c o nne c tio n is b ro ke n a nd p o we r is c ut to the unit. T his
e nsure s sa fe a c c e ss to the unit fo r se rvic ing a nd c le a ning .
NB - WHEN REPL AC ING T HE C AT C H T RAY BAC K INT O EXO C UT O R
FUL L Y INT O PO SIT IO N AND T HAT PO WER IS REST O RED T O T HE UNIT .
T UBE REPL AC EMENT
T UBE REPLAC EMENT SHO ULD BE C ARRIED O UT BY SERVIC E PERSO NNEL O NLY, AFT ER
ENSURING T HAT T HE UNIT IS DISC O NNEC T ED FRO M T HE MAINS SUPPLY.
T o e nsure the e ffic ie nc y o f
b e re p la c e d a nnua lly. Afte r twe lve mo nths the p ho sp ho r c o a ting tha t e mits the
c o rre c t wa ve le ng th o f UV lig ht ha s b urnt a wa y a nd the UV o utp ut is d iminishe d
sub sta ntia lly.
T o re p la c e the UV tub e s...
1. Re mo ve the c a tc h tra y, b re a king the p o we r sup p ly to the unit.
2. Ro ta te the tub e thro ug h 90°, fre e ing it fro m the tub e ho ld e rs.
3. Pull the tub e a wa y fro m the c ha ssis.
4. Disp o se o f the use d UV tub e s in c o njunc tio n with lo c a l WEEE re g ula tio ns.
ST ART ER REPL AC EMENT
ST ART ER REPLAC EMENT SHO ULD BE C ARRIED O UT BY SERVIC E PERSO NNEL O NLY,
AFT ER ENSURING T HAT T HE UNIT IS DISC O NNEC T ED FRO M T HE MAINS SUPPLY.
T he sta rte rs p ro vid e a n e xtra sp a rk to initia lly lig ht the UV tub e s. Sta rte rs we a r o ut
a nd sho uld b e re p la c e d a t the sa me inte rva ls a s the UV tub e s.
T o re p la c e the sta rte rs...
1. Ro ta te the sta rte r a nti-c lo c kwise .
2. Pull the sta rte r fre e fro m the unit.
SPEC IFIC AT IO N / REPL AC EMENT PART S
Unit EX16
230V ~ 50Hz
Vo ltag e
Dim e nsio ns(m m ) 390 x 140 x 265
50 Sq . Me te rs
C o ve rag e
We ig ht 3.3 Kg
16W
L ig ht O utput
2 x T PX8-12
T ub e s
2 x I154
Starte r
T -EX16W / T -EX16S
T ray (W / S/ S)
EX40
Unit
230V ~ 50Hz
Vo ltag e
694 x 140 x 265
Dim e nsio ns(m m )
140 Sq . Me te rs
C o ve rag e
We ig ht 5.6 Kg
40W
L ig ht O utput
T ub e s 2 x T PX18-24
2 x I154
Starte r
T ray (W / S/ S) T -EX40W / T -EX40S
R3 03/14
