FORlight Helix Bedienungsanleitung

Helix
LUMINOTECHNIC FEATURES
CRI: 80
MacAdam steps: 3
Photobiological risk: RG0
Lampholder Quantity Light source
power (W)
LED 1 6W
VENTILATION FEATURES
Blade finish: Wood
Blade material: ABS
Maximum sound level (dB): 43
Minimum sound level (dB): 37
Maximum flow: 127.43
Power used: 6.6W
Service value: 19.31
Standby mode consumption: 0.5
Acostic potential level: 43
Maximum air speed (m/s): 14099.47
Service value measurement standard: EN 60879:2019
EMERGENCY MODULE FEATURES
Battery type: PILA
LOGISTICS
VE-0002-MAD
Fan IP20 Helix LED LED warm-white 3000K Imitation wood Wood 540.00
TECHNICAL FEATURES
Luminaire total power : 6.6W
Real lumens : 274
Nominal lumens : 540
Real lm/W : 42
Correlated Colour Temperature (CCT) : LED warm-
white 3000K
Lens / reflector angle : HORIZONTAL 126º
Structure material : Steel
Structure finish : Imitation wood
Diffuser material : Glass
Diffuser finish : Opal
Installation Instructions
IP20
Voltage / frequency : 220-240V/50-60Hz
Useful life : 36.000h L70B30
Warranty : 5 Years
W
1 2 3 4 5
99 132 156 175 204
4 8 14 21 36
