Nextool LIGHT 1000 LM MULTI Gebrauchsanleitung

Nextool
Flashlight
User Manual
ORFLASHLIGHT02
Read this manual carefully before using the flashlight and keep it for future reference.
Characteristics
1. Practical 6-in-1 multifunctional flashlight: flashlight, camping flashlight, working light, signal warning light, portable
charger, acoustic optical alarm.
2. Ideal for all kinds of activities: car trips, outdoor getaways or defense tool. The Thunder flashlight provides you
with all the light you require at any time.
3. The maximum brightness intensity of the flashlight is 1000 lumens and the greatest beam distance is 240 meters. It
incorporates patented Fresnel lens, telescopic focusing and quick switching between spotlight and floodlight.
4. The intense sound alarm, together with the strobe e ect light, o ers double protection against any danger.
5. The red and white side light works as both illumination and emergency light. Its magnetic fixing system allows you
to have your hands free.
6. It can be used as an emergency portable charger to ensure that your phone is always operational in case of
emergency.
Specifications
Photoelectric
measurement
parameters
Brillo
1000lm
Tiempo de funcionamiento
Distancia de alcance
Impact resistance
Water resistance
Dimensions
Weight
Material
Charge
Battery
The above parameters strictly conform to the standard test Q/GDBCY 015-2019. The battery used was a 1×18650
(2600mAh) lithium-ion battery. If the tested battery or environment is di erent, the performance parameters may
di er.
Focusing Flashlight
High Medium Low
180lm 40lm
2.5h 6h 24h
240m 100m 40m
1 m
IPX4
34 mm (body diameter) x 160.5±2 mm (length)
203.5g±5g (accessories not included)
Aerospace aluminium 6061-T6 and ABS plastic, Type II Anodised nish
Type-C Charge, 5V 1A, Charging Time ≈3.5 hours, (USB-A Port, 5V 1A, 1400mAh Battery Capacity)
1 x 18650 Li-Ion Battery, 2600mA 3.6V 9.36W
Side light
(working light/camping light/signal light)
Low High Red light
20lm 200lm 6lm
48h 4h 24h
5m 15m ----
Acoustic optical alarm
Red and white strobe
lights
----
Buzzer alarm and strobe
90h
----
S.O.S
light
Operating time 5h
