Vale 28cm
ceramics
CL/03.02160 - CL/03.03160 - CL/03.30160
Montage instructies
Installation instructions
Notice de montage
Montageanweisungen
REV 01
20.11.2020

Werbung

loading

Inhaltszusammenfassung für Clou Vale CL/03.30160

  • Seite 1 Vale 28cm ceramics CL/03.02160 - CL/03.03160 - CL/03.30160 Montage instructies Installation instructions Notice de montage Montageanweisungen REV 01 20.11.2020...
  • Seite 2 - Clou b.v. can not be held responsible for - Clou b.v. kan niet verantwoordelijk worden the results of improper use, improper gesteld voor de gevolgen van onaangepast...
  • Seite 3 éventuellement Für andere Wände ist die verwendeten consolider le mur si nécessaire. regelnmittel an eigener Verantwortlichkeit, - Clou se réserve le droit pour tout und die Wand konnte Verstärkung changement technique ou optique par benötigen. rapport à la photo représentant le produit.
  • Seite 4 Gegenstände auf das Produkt passend ist. Gebruiksvoorschriften: zie ook de onderhoudsvoorschriften op www.clou.nl User’s instructions: See also the maintenance guides at www.clou.nl max. Instructions d’utilisation: Voyer aussi les instructions de maintenance sur www.clou.nl 15 kg Gebrauchsanweisungen: Sehen Sie auch die Wartungsanweisungen am www.clou.nl...
  • Seite 6 CL/03.02160 - CL/03.03160 - CL/03.30160 norm. 720 max. 765 min. 685 imensions in mm, for reference only / 08.04.2020 / rev_01 www.clou.nl...
  • Seite 7 Plaats de afvoerplaat met sanitairkit tegen de fontein aan. Place the drain plate onto the hand basin with silicone paste for sanitary. Placer la plaque de vidange sur le lave-mains avec du mastic sanitaire. Platzieren Sie die Ablaufplatte mit einem Sanitär Silikon-Dichtmasse gegen das Handwaschbecken.
  • Seite 8 Duidt met potlood en waterpas de positie van de afvoer van de fontein aan. Mark with pencil and spirit level the position of the drain of the hand basin. Marquer avec un crayon et avec un niveau la ligne de la position de la bonde du lave-mains.
  • Seite 9 X-line Duidt met potlood de plaatsen aan waar u gaten moet boren. Mark with pencil the spots 100mm 100 mm to drill holes. Marquer avec un crayon les endroits de perçage des trous. Markieren Sie mit einem Bleistift die Stellen an, denen Löcher gebohrt werden müssen.
  • Seite 10 Steek de pluggen in de gaten en schroef de stokschroeven in de pluggen. Insert the dowels in the holes and screw the dowel screws in the dowels. Enfoncer les chevilles dans les trous et visser les goujons dans les chevilles. Bringen Sie die Dübel in den Löchern und Schrauben Sie die Stockschrauben in die...
  • Seite 11 Bevestig de kraan (niet inbegrepen) aan de muur en sluit deze aan op de waterleiding. Mount the tap (not included) on the wall and connect it to the water supply. Fixer le robinet (non inclus) sur le mur et le raccorder à la conduite d’eau.
  • Seite 12 Clou. Bath findings. Clou bv Thermiekstraat 1 NL-6361 HB Nuth T +31 (0)45 524 56 56 info@clou.nl www.clou.nl Looking for inspiration?
