INSTALLATION AND
ADJUSTMENT MANUAL
M000252
SMS Casing Wall
DE Handbuch für Installation und Anpassung
IT Manuale per l'installazione e la regolazione
ES Manual de instalación y ajuste
FI Asennus- ja säätöohje
FR Manuel d'installation et de réglage
NL Handboek voor installatie en instellingen
PL
RUS
ARB
SE Monterings- och justeringsmanual
GR
Werbung
Verwandte Anleitungen für SMS Casing Wall
Inhaltszusammenfassung für SMS Casing Wall
- Seite 1 INSTALLATION AND ADJUSTMENT MANUAL M000252 SMS Casing Wall DE Handbuch für Installation und Anpassung IT Manuale per l'installazione e la regolazione ES Manual de instalación y ajuste FI Asennus- ja säätöohje FR Manuel d’installation et de réglage NL Handboek voor installatie en instellingen...
- Seite 2 Η σωστή εγκατάσταση χρειάζεται ιδιαίτερη προσοχή και δεν αποτελεί ευθύνη της SMS Evoko Group montering kan resultera i person och sakskador. SMS friskriver sig från allt ansvar av vad slag det må vara AB. Λανθασμένη εγκατάσταση μπορεί να προκαλέσει ανθρώπινο τραυματισμό ή υλικές ζημιές.
- Seite 3 Nei casi in cui si faccia riferimento alla garanzia, si deve inviare a SMS il prodotto insieme alla purchase receipt are to be returned to SMS. The name of the supplier and the date of purchase must ricevuta d’acquisto in originale. Sulla ricevuta devono essere chiaramente leggibili nome del be clearly legible on the receipt.
- Seite 4 4 SMS CASING WALL ASSEMBLY INSTRUCTIONS YOU WILL NEED No.10 NOT INCLUDED Max. weight 55 kgs Display (1x) NUMBER OF PERSONS REQUIRED...
-
Seite 5: List Of Parts
SMS CASING WALL LIST OF PARTS (1x) (2x) (2x) (1x) (4x) (4x) M6x16 Nut M6 SCREW LIST Screw M6x25 Nut M6... - Seite 6 6 SMS CASING WALL SCREW KIT Safety allen key K1 SCREW KIT Screw M6x16 Screw M6x30 Screw M8x20 Screw M8x25 Screw M8x35 Multiple Washer Plastic spacer 8,2/15x10 Plastic spacer 8,2/15x15...
- Seite 7 SMS CASING WALL Mounting Instructions: SMS Casing Wall- Landscape Prepare wall frame No.10 (4x)
- Seite 8 8 SMS CASING WALL Drill holes (1x) Min 70mm Min 70mm Use wall screws to suit wall type...
- Seite 9 SMS CASING WALL Level frame Drill holes Min 70mm Min 70mm...
- Seite 10 10 SMS CASING WALL Use wall screws to suit wall type Mount bracket on display SCREW KIT...
- Seite 11 SMS CASING WALL Mount display on wall bracket Display depth adjustment Push/pull to adjust depth...
- Seite 12 12 SMS CASING WALL (4x) Padlock optional...
- Seite 13 SMS CASING WALL Mounting Instructions: SMS Casing Wall- Portrait Prepare wall frame No.10 (4x)
- Seite 14 14 SMS CASING WALL Drill holes (1x) Min 70mm Min 70mm Use wall screws to suit wall type...
- Seite 15 SMS CASING WALL Level frame Drill holes Min 70mm Min 70mm...
- Seite 16 16 SMS CASING WALL Use wall screws to suit wall type Mount bracket on display SCREW KIT...
- Seite 17 SMS CASING WALL Mount display on wall bracket Display depth adjustment Push/pull to adjust depth...
- Seite 18 18 SMS CASING WALL (4x) Padlock optional...
-
Seite 19: Product Dimensions
SMS CASING WALL PRODUCT DIMENSIONS 3,25-4,23 82.5-107,5 All dimensions in mm. Dimensions in brackets [ ] are in inches SMS Casing Wall Product Measurements ( W x H ) Max Display Measurements 32" 779 x 471 mm [ 31,46”x 18,54”] 740 x 444 x 64 mm 1022 x 608 mm [ 40,24”x 23,94”]...
