PRODUCT DESCRIPTION

Baby monitor description
1 Status indicator
2 Microphone
3 Call/pair button
4 LED light
Display description
1 Microphone
2 Charging indicator light
3 In-use indicator light
4 Zoom in/out
5 Menu
6 Directional buttons
7 Confirm
8 Call
OPERATING INSTRUCTIONS
Connecting the baby monitor to the app
1. Make sure your Wi-Fi network is 2.4GHz. The baby monitor does not support
5GHz networks.
2. Download the Concept Home app to your mobile phone. Register or log in
to your account.
3. Restart the baby monitor using the restart pin (included).
4. Follow the instructions in the app on your mobile phone.
Connecting the baby monitor to the camera
Switch on the camera and monitor, both will connect automatically.
If the connection fails, follow the steps below to pair the devices.
1. On the monitor screen, press the Menu button and select Camera.
2. Long press the pairing button on the camera until you hear a tone.
3. Press the OK button on the monitor screen to start pairing.
32
5 SD card slot
6 Speaker
7 MicroUSB power supply
connector
8 Restart button
9 Back
10 Antenna
11 ON/OFF button
12 Speaker
13 Monitor bracket
14 SD card slot
15 Restart
16 MicroUSB connector
KD4010
Baby monitor features
Motion/sound detection - The baby monitor can detect motion and sound and
then send a notification to your phone.
LED light/lullaby - When your baby cries, you can play a lullaby or turn on the
night light. There are different lullaby and light modes to choose from.
Downloading the app
Find and download the Concept Home app from Google Play or App Store to
your mobile phone.
If you already have Concept Home, open the app, sign in, and continue with the
pairing instructions.
App
Register or log in to the app.
• Once logged in, click on "Přidat zařízení" ("Add device") (see Figure 1) and
then select the icon of the desired device, in this case "Kamera (Wi-Fi)"
("Baby Monitor (Wi-Fi)") in the "Video dohled" ("Video monitoring") section
(see Figure 2).
• Connect the device using the USB cable and hold the button on the front
of the baby monitor until it beeps 3 times, then click "Další" ("Next") (see
Figure 3)
• Enter the login information for your wireless network (see Figure 4).
• A QR code will appear on your mobile phone display and you can point it at
the monitor from a distance of 15-20 cm. After successful pairing, the baby
monitor will beep 3 times again. Then click on the "Ozve se pípnutí" ("Beep")
button (see Figure 5). The baby monitor will now connect to your mobile
phone (see Figure 6).
• Once the baby monitor is successfully connected to your mobile phone, you
can rename your device and then click on "Dokončit" ("Finish") (see Figure
7).
Baby monitor installation options
You can place the baby monitor on a flat surface (see Method 1 figure), or mount
it on the wall using the included mounting bracket (see Method 2 figure).
