Westmann Roma 2000 Montageanleitung Seite 3
MONTAGEANLEITUNG Westmann Hollywoodschaukel Roma 2000
SERVİS KARTI
SERVICE CARD
SERVICE KARTE
ROMA 2000 1. PAKET
1.PAKET
1
Y3111111341701022 Roma Uzun Ayak Sol Çam 1760x95x40 mm (Ceviz Vernik)
2
Y3111111331701022 Roma Uzun Ayak Sağ Çam 1760x95x40 mm (Ceviz Vernik)
3
Y3111111191701006 Roma Kısa Ayak Sol Çam 1295x95x40 mm (Ceviz Vernik)
4
Y3111111181701006 Roma Kısa Ayak Sağ Çam 1295x95x40 mm (Ceviz Vernik)
5
Y3111111131701022 Roma Ara Kayıt Alt Çam 1760x95x40 mm (Ceviz Vernik)
6
Y3111111141701022 Roma Ara Kayıt Üst Çam 1760x95x40 mm (Ceviz Vernik)
7
Y3111117321701024 Roma Tente Çıtası Çam 1850x28x22 mm (Ceviz Vernik)
8
Y1401000901750000 Roma 2000 Montaj Paketi
8.1
H15004012001 Torks Anahtarı
8.2
H15004016001 T30 Torks Uç
8.3
H15004016002 T40 Torks Uç
8.4
H15004003006 Vida Torks HB Galvanizli (Beyaz) 8x140
8.5
H15004003004 Vida Torks HB Galvanizli (Beyaz) 6x60
8.6
H15004007007 Pul Buldeks HB Özel 19x5
8.7
H15004003008 Vida Buldeks Galvanizli (Beyaz) 7.5x60
8.8
H15004002006 Civata Yıldız Başlı Siyah Bakalit M8x40
8.9
H15004007002 Pul İnce Galvanizli Beyaz 3/8
8.10
H15004008001 Çatallı Mafsal Katlanır Yay Bulonlu M10x1.25 Diş
8.11
H15004006001 Burç Poliamid 19x10 mm
8.12
H15004007004 Pul Galvanizli Beyaz 30x10x1
ROMA 2000 2. PAKET
2.PAKET
9
H15004014004
10
Y4111119441750000 Roma 2000 Oturak ve Sırt iskeleti Vida Montajlı Çam (Ceviz Vernik)
10.a
Y3111119391750000 Roma 2000 Oturak İskele Vida Montajlı Çam (Ceviz Vernik) Roma 2000 Seat Frame Screw Assembled Pine (Walnut Varnish)
10.b
Y3111119401750000 Roma 2000 Sırt İskele Vida Montajlı Çam (Ceviz Vernik)
11
Y3111117351701003 Roma Yan Tente Çıtası Çam 1130x95x22 mm (Ceviz Vernik) Roma Side Canopy Lath Pine 1130x95x22 mm (Walnut Varnish)
12
Y3111111101701051 Roma A Ara Kayıt Sol Çam 810x95x22 mm (Ceviz Vernik)
13
Y3111111461501051 Paris A Ara Kayıt Sağ Çam 810x95x22 mm (Ceviz Vernik)
14
Y530000055175T101 Roma 2000 Tente T/BEYAZ-B/KREM
15
Y630202053175T101 Roma 2000 Sırt/Font Minderi Dolgulu T/BEYAZ
11
12
1 1
1 1
Roma Ana Askı Demiri Yataklı
14
6
9
10.b
10
5
3
Package 1
Roma Long Leg Left Pine 1760x95x40 mm (Walnut Varnish)
Roma Long Leg Right Pine 1760x95x40 mm (Walnut Varnish)
Roma Short Leg Left Pine 1295x95x40 mm (Walnut Varnish)
Roma Short Leg Right Pine 1295x95x40 mm (Walnut Varnish)
Roma Support Slat Lower Pine 1760x95x40 mm (Walnut Varnish)
Roma Support Slat Upper Pine 1760x95x40 mm (Walnut Varnish)
Roma Canopy Lath Pine 1850x28x22 mm (Walnut Varnish)
Roma 2000 Assembly Package
Torx Key
T30 Torx Bit
T40 Torx Bit
Screw Torx HB Galvanized (White) 8x140
Screw Torx HB Galvanized (White) 6x60
Washer Buldex HB Özel 19x5
Screw Buldeks Galvanized (White) 7.5x60
Bolt Phillips-head Black Bakelite M8x40
Washer Thin Galvanized White 3/8
Fork Link Universal Joint Spring Bolted M10x1.25 Thread
Bushing Polyamide 19x10 mm
Washer Galvanized White 30x10x1
Package 2
Roma Main Hang Steel with Bed
Roma 2000 Seat and Back Frame Screw Assembled Pine (Walnut Varnish) AD 1
Roma 2000 Back Frame Screw Assembled Pine (Walnut Varnish)
Roma A Support Slat Left Pine 810x95x22 mm (Walnut Varnish)
Roma A Support Slat Right Pine 810x95x22 mm (Walnut Varnish)
Roma 2000 Canopy T/WHITE-B/BEIGE
Roma 2000 Back/Font Cushion Filled T/WHITE
11
2
7
13
15
10.a
3/20
4
AD 1
AD 1
AD 1
AD 1
AD 1
AD 1
AD 1
AD 1
AD 2
AD 1
AD 1
AD 1
AD 1
AD 10
AD 4
AD 4
AD 4
AD 4
AD 4
AD 2
AD 2
AD 2
AD 1
AD 1
TK 1
AD 1
AD 1
AD 2
AD 2
AD 2
AD 1
AD 1
