- Scan the QR code on the watch (Settings - QR Code) - on the App “FF1(ID-****) would like to pair with your phone.” that pops up, select “Pair” - to achieve a successful con- nection (Bluetooth Name: Parsonver FF1 ) Note: 1 )Turn on the Bluetooth on the mobile phone.
1 )Click to turn off call audio, then turn it on again, and check 2)Need to find “Settings” on the mobile phone - Click “Bluetooth” - Find the Bluetooth name of the watch “Parsonver FF1” - Click to connect Menu type Do not disturb Mute mode...
2.Swipe Up to enter message interface. 3.Swipe Right to enter recently used menu interface. 4.Swipe Left to enter daily exercise, sleep, heart rate, blood oxygen, weather interface. 5.When the screen is on, press the side button to enter menu interface. 6.Press and hold the main interface to select the watch face.
Seite 5
Do not disturb QR Code Set the start time and end Scan to connect to the time of “Do not disturb” watch or download the mode. APP. System Info “Reboot”, “Power off”, “Re- Check “Device name”, set” the watch. “Device version”, “Bluetooth address”.
Seite 6
Monitor heart rate, and slide down on the interface to view heart rate change chart for a week Note: To view the 24-hour real-time heart rate change graph, open the app and find the third small icon “De- vice” at the bottom of the page - Click “Heart rate set- tings”...
Seite 7
Voice Assistant Click to wake up the voice assistant Note: Need to turn on “Media audio” on Settings of the watch. Open the app - Click the third small icon “Device” at the bottom - Click “SOS Contact” to set Female Health Open the app - Click the fourth small icon “Profile”...
Seite 8
Note: 1) The rated voltage of the charging head is 5V/0.5A. 2)Please do not use the vehicle power supply to charge, to avoid causing the charging cable to age or burn out due to the unstable voltage. Replace the watchband Slide the switch of the watch- band, and replace the same specification(watchband width:...
Scannez le code QR sur la montre (Paramètres - Code QR)-”Êtes-vous d’accord pour jumeler avec le télé- phone ?” apparaît sur la montre, sélectionnez “Jumeler” - connexion réussie (Parsonver FF1) Remarque : 1 ) Activez le Bluetooth sur le téléphone mobile.
’’ est allumé ; ② Sur le téléphone portable, recherchez “Paramètres” - cliquez sur “Bluetooth” - recherchez le nom Bluetooth de la montre “Parsonver FF1” - il vous suffit de cliquer pour vous connecter. Ne pas déranger Sélection de menu Réglage...
Seite 11
Paramètre Lampe de poche Scannez le code QR pour vous connecter à la montre ou téléchargez l’APP. 2. Glissez vers le haut pour accéder à l’interface des messages. 3. Glissez vers la droite pour accéder à l’interface de menu récemment utilisée. 4.
Seite 12
Mot de passe Réglez “Commutateur de Mot de Passe”, en cas d’oubli du mot de passe, veuillez réinitialiser la montre aux paramètres d’usine dans l’application mobile. Lever pour Activer Activer/désactiver “Lever pour Activer”. Ne pas déranger Réglez l’heure de début et l’heure de fin du mode “Ne pas déranger”.
Seite 13
Cliquer sur “ ” pour raccrocher, cliquer sur “ ” pour régler le volume, cliquer sur “ ” pour activer / désactiver le microphone. Le correspondant peut vous entendre lorsque le microphone est active, mais ne peut pas vous entendre lorsque le microphone est désactivé. Réglage de la Personne à...
Seite 14
Remarque : glissez vers la droite sur l’interface pour continuer/quitter le mode d’entraînement, balayez vers la gauche pour accéder à l’interface de contrôle de la musique. Oxygène Sanguin Surveiller l’oxygène sanguin et afficher le graphique de changement d’oxygène dans le sang sur 24 heures, ouvrez l’application et trouvez la troisième petite icône “Appareil”...
Seite 15
Santé des Femmes Ouvrez l’application et trouvez la quatrième petite icône “Moi” en bas de la page - Cliquez sur “Cycle physi- ologique” pour définir des rappels. Remarque : Lors de l’enregistrement d’un compte, le sexe doit être féminin. Ouvrez l’application - Cliquez sur la quatrième petite icône “Moi”...
Remplacement du Bracelet de la Montre Faites glisser l’interrupteur du bracelet de montre et rem- placez la même spécification (largeur du bracelet : 22 mm). Précautions à prendre 1. Gardez votre montre propre. 2. Portez la montre correctement, ni trop serrée ni trop lâche pour éviter l’inconfort.
Ecke - Scannen Sie den QR-Code auf der Uhr (Einstellungen - QR-Code) – Popup in der App „Sind Sie mit der Handy-Kopplung einverstanden?“ „Koppln“ auswählen - um eine erfolgreiche Verbindung herzustellen (Bluetooth Name: Parsonver FF1 ) Hinweis:...
Sie ihn dann wieder ein, und überprüfen ein. 2)Sie müssen „Einstellungen“ auf dem Mobiltelefon finden – Klicken Sie auf „Bluetooth“ – Suchen Sie den Bluetooth-Namen der Uhr „Parsonver FF1“ – Klicken Sie, um eine Verbindung herzustellen. Menütyp „Nicht stören“-Modus...
Handy finden „Handgelenk weck- en“ ein-/ausschalten Hinweis: Sie müssen das Medienaudio der Uhr aus- schalten. Scannen Sie, um sich mit der Uhr zu verbinden, oder laden Sie die APP herunter 2.Wischen Sie nach oben, um die Nachrichtenschnitt- stelle aufzurufen. 3.Wischen Sie nach rechts, um die zuletzt verwendete Menüoberfläche aufzurufen.
Seite 20
Stellen Sie die „Vibration“-Intensität ein, schalten Sie „Medien-Audio“ ein und schalten Sie den „Stummmo- dus“ ein. Hinweis: Wenn das Medienaudio eingeschaltet ist, kann die Uhr die Tonwiedergabe aller Mobiltelefone wie Spra- chassistent und Musikwiedergabe realisieren. Passwort Stellen Sie „Passwort-Schalter“ ein, wenn Sie das Pass- wort vergessen haben, setzen Sie die Uhr bitte in der mobilen APP auf die Werkseinstellungen zurück.
Seite 21
Sie können „Kontakte“ auswählen oder „Wähltasten“ verwenden, um Anrufe zu tätigen. Und Sie können „An- rufprotokolle“ auf der Uhr überprüfen. Hinweis: Klicken Sie , um aufzulegen, klicken Sie um die Lautstärke einzustellen, klicken Sie , um das Mikrofon ein-/auszuschalten. Der andere Teilnehmer kann Sie hören, wenn das Mikrofon eingeschaltet ist, aber nicht, wenn das Mikrofon eingeschaltet ist ist aus.
Seite 22
zfrequenz, Schritte, Kalorien usw. anzuzeigen, wischen Sie nach rechts, um den Trainingsmodus fortzusetzen/ zu beenden, wischen Sie nach links, um die Musiksteuer- ungsoberfläche aufzurufen. Blutsauerstoff Überwachen Sie den Blutsauerstoff und sehen Sie sich das 24-Stunden-Blutsauerstoff-Änderungsdiagramm an, öffnen Sie die App und suchen Sie das dritte kleine Symbol „Gerät“...
Öffnen Sie die App - Klicken Sie unten auf das dritte kle- ine Symbol „Gerät“ - Klicken Sie zum Einstellen auf „SOS- Kontakt“. Weibliche Gesundheit Öffnen Sie die App - Klicken Sie unten auf das vierte kleine Symbol „Mein Profil“ - Klicken Sie auf „Physiolo- gischer Zyklus“, um Erinnerungen festzulegen.
Hinweis: 1) Die Nennspannung des Ladekopfes darf 5V/0.5A nicht überschreiten. 2)Bitte verwenden Sie zum Laden nicht das Auto-Power, um zu vermeiden, dass das Ladekabel aufgrund der instabilen Spannung altert oder durchbrennt. Armband ersetzen Schieben Sie den Schalter des Armbands und ersetzen Sie es mit der gleichen Spezifikation (Armbandbreite: 22mm).
Seite 25
QR del reloj (Ajustes - Código QR) > Seleccionar “Emparejar” cu- ando aparezca “¿Está de acuerdo en emparejar con su teléfono?” > Conectado (Nombre Bluetooth: Parsonver *** ) Nota: 1) Confirmar si el Bluetooth del teléfono está activado.
ración del teléfono. 4) Si el Bluetooth se conecta correctamente, se ilumi- nará la señal en la esquina superior izquierda de la interfaz principal, de lo contrario, la señal aparecerá en gris. 5) Para seleccionar el idioma, puede hacer clic en “Dis- positivo”...
cionar la esfera del reloj. 7. Pulsar una vez el botón lateral para volver a la interfaz anterior. 8. Mantener pulsado el botón lateral durante 3 segun- dos para apagar el reloj. Modo de configuración Esfera Elegir Esfera del reloj, y hacer clic en el botón lateral para volver a la interfaz anterior.
Seite 28
Escanear para conectarse al reloj o descargar la APP. Sistema “Reiniciar”, “Apagar”, “Reiniciar” el reloj. Información Comprobar “Nombre del dispositivo”, “Versión del dis- positivo”, “Dirección Bluetooth”. Pulsar el botón lateral para entrar en el menú y ver más funciones cuando la pantalla está encendida Llamar Poder seleccionar “Contactos”...
Seite 29
cardiaca en tiempo real durante 24 horas, puedes abrir la aplicación > Dispositivo > Ajustes de frecuencia cardiaca > Activar “Automático” y “Recordatorio de frecuencia cardiaca máxima”. Cuando la frecuencia cardiaca supere este valor, el dispositivo vibrará para recordárselo. Entrenamiento Elegir un modo de entrenamiento, deslizar hacia abajo en la interfaz para ver el tiempo de entrenamiento, la frecuencia cardíaca, los pasos, las calorías, etc., desli-...
Seite 30
Asistente de voz Pulsar para activar el asistente de voz Nota: Es necesario activar “Audio multimedia” en Ajustes del reloj antes. Abrir la aplicación>Hacer clic en Dispositivo>Configuar el Contacto SOS Salud Femenina Abrir la aplicación>Perfil>Hacer clic a Ciclo fisiológico para establecer recordatorios. Nota: Al registrar una cuenta, el sexo debe ser femenino.
Seite 31
1) El voltaje nominal del cabezal de carga es de 5V/0,5A. 2)Por favor, no utilice la fuente de alimentación del vehículo para cargar, para evitar que el cable de carga envejezca o se queme debido a la tensión inestable. Sustitución de la correa del reloj Deslizar el interruptor de la cor- rea del reloj y cambiarla por otra del mismo tamaño (ancho...
Seite 32
QR sull’orologio (Impostazioni - Codice QR) - Selezionare “Conferma” nella finestra pop-up dell’app che chiede “Vuoi accoppiare con il telefono?” - per ottenere una connessione riuscita (Nome Bluetooth: Parsonver FF1). Nota: 1) Accendere il Bluetooth sul telefono cellulare.
Seite 33
1 )Fare clic per disattivare l’audio e poi riattivarlo per verificare che l’icona sia illuminata. 2 )Aprire “Impostazioni” sul telefono, fare clic su “Bluetooth”, trovare il nome del Bluetooth dell’orologio “Parsonver FF1” e fare clic per connettersi. Modalità Selezione del menu non disturbare Alza per attivare Luminosità...
2. Scorrere verso l’alto per accedere alla schermata dei messaggi. 3.Scorrere da sinistra a destra per accedere alla scher- mata dei menu recenti. 4. Scorrere da destra a sinistra per accedere alle schermate di monitoraggio attività quotidiana, sonno, frequenza cardiaca, saturazione di ossigeno e meteo. 5.
Seite 35
È possibile impostare una password per lo schermo di blocco. Se la password viene dimenticata, è possibile ri- pristinare l’orologio alle impostazioni di fabbrica tramite l’app del telefono. Alza per attivare Attivare/disattivare “Alza per attivare”. Codice QR Scansionare il codice QR per connettere l’orologio o scaricare l’app.
Seite 36
Selezionare “OK” quando appare “Vuoi accedere ai tuoi contatti” sull’app “GloryFit” per sincronizzare i contatti con l’orologio. Esercizio quotidiano Scorrere verso il basso sull’interfaccia per controllare “Calorie”, “Distanza”, “Passi” (dettagli dei passi e dati set- timanali). Frequenza cardiaca Monitorare la frequenza cardiaca e scorrere verso il basso sull’interfaccia per visualizzare il grafico della variazione della frequenza cardiaca per una settimana.
Seite 37
Sonno Monitora i dati sul sonno, scorrere l’interfaccia verso il basso per visualizzare il tempo di veglia, di sonno leggero, di sonno profondo e il movimento rapido degli occhi. Il tempo Controllare le condizioni meteo, scorrere verso il basso per visualizzare il tempo futuro per i tre giorni succes- sivi.
Scuotere per scattare una foto Aprire l’app - Fare clic sulla terza piccola icona “Disposi- tivo” in basso - Fare clic su “Altre impostazioni” - Fare clic su “Scuoti per scattare foto”. Aprire l’applicazione - Fare clic sulla terza piccola icona “Dispositivo”...
Seite 39
sull’orologio prima di utilizzarlo. Non indossare l’orologio per nuotare. Se l’orologio si bagna, prima di metterlo in funzione è necessario asci- ugare l’acqua dall’orologio. Precautions Numero di TFT da 1,91 Display modello pollici Risoluzione 240*296px Bluetooth Capacità Tempo di della bat- 320mAh 5-7 giorni lavoro...
Seite 47
仕様 1.91インチ モデル ディスプレイ 解像度 240*296px Bluetooth BLE 5.2 電池容量 320mAh 電池寿命 5-7日間 動作温度 0-45℃ 保存温度: -10 - 50℃ 定格電圧 3.8V 定格電流 190mA 対応システム Android 5.0以降/iOS 10.0以降...
Seite 48
This device contains licence-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two condi- tions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device.
Seite 49
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursu- ant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio...
Seite 50
Model number: FCC ID: Brand Name: 2A7YB-FF1 Parsonver HVIN: 30206-FF1 MADE IN CHINA...
