Installation
1. Remove the insulated strip, the detector will enter working mode.
2. Use screw to fix the probe horizontally on the detection site.
3. Use double-sided adhesive tape to fix the transmitter on the place
where the liquid is normally unable to reach, and keep the antenna
upward.

Change Batteries

Open the back case with screwdriver, and replace the batteries with
new ones according to the positive and negative marks.
Specifications
Power supply: DC 3 V (AAA 1.5 V LR03 x 2 PCS)
Static current: < 29 uA
Alarm current: < 23 mA
Transmitting distance: < 80 m (in open area)
Radio frequency: 433.92 MHz
Housing material: ABS plastic
Operating condition:
Temperature: -20 °C ~ +55 °C
Relative humidity: < 80% (non-condensing)
Detector dimensions (L x W x H):
Probe dimensions (L x W x H): 35 x 30 x 15 mm
54 x 14.5 x 107 mm
