FRAME ASSEMBLIES T3
I
DIAGRAM
1
3
2
7
4
5
6
1
2
3
6
STAND
ITEM # PART #
1 600-198
2 600-351
3 599-439
4 599-215-L
5 599-215-R
6 600-398
HI CART
ITEM # PART #
1 599-391
2 599-439
3 600-373
4 600-399
5 600-468
6 599-397
7 599-395
4
5
63
DESCRIPTION
SCREW
CUP
BOLT
STAND LEG (LEFT)
STAND LEG (RIGHT)
FRAME CAP
DESCRIPTION
HI CART FRAME
BOLT
WHEEL
RETAINING RING
WASHER
FRAME CAP
HI CART COMPLETE
QTY
1
1
4
1
1
4
QTY
1
4
2
4
4
2
1
REV 5/2023
