Buttons and functions

1. Display

2. Control panel

3. IR remote control
receiver
4. Air outlet
5. Water level
indicator
6. Carrying handle
7. Remote control
storage bay
8. Air inlet
9. Mains lead holder
10. Mains lead
11. Water reservoir
12. Water reservoir lock
Control panel
13. [ OFF ] Switches the air cooler to standby mode which means that the air cooler is off but not
disconnected from the electricity network. The air cooler can be completely disconnected
from the electricity network by unplugging it from the wall socket.
14. [ COOLER ] Switches the cooling and humidifying function on/off.
15. [ TIMER ] Selects how long the air cooler is to be switched on: 1, 2, 4 or 8 hours.
The air cooler will turn off automatically once the set time has passed.
16. [ LEFT/RIGHT ] Oscillation of the vertical louvre on/off.
17. [ UP/DOWN ] Adjusts the horizontal louvre.
18. [ MODE ] Selects fan mode: normal, nature or sleep.
- Normal: constant fan speed
- Nature: In nature mode the fan speed will vary according to a fixed pattern and depending
on the fan speed selected. The fan alternates between: off, low, medium and high.
1
2
3
4
5
OFF COOLER TIMER
13 14 15
3
6
7
8
9
10
11
12
LEFT/RIGHT UP/DOWN MODE
ON/SPEED
16 17 18 19
