Important notes
about installation
The MultiDock must be fitted exclusively
by a specialist sanitary engineer.
Generally accepted engineering prac-
tices should be applied. (In particular,
compliance with DIN EN 1717 is recom-
mended)
The MultiDock must be installed only
above the bathtub or shower tray.
The MultiDock is suitable for both bath
and shower applications. If you need
only one outlet, choose either the top
or the bottom outlet and connect it.
Close the unused outlet with a plug that
included in complete set.
The hot and cold supplies must be of
equal pressures. Difference of cold and
hot water pressure should not exceed+/-
10%.
The hot water supply must be connect-
ed to the left and cold water supply to
the right tube of the MultiDock.
Installation depth: from 80 mm to 108
mm.
The MultiDock can be installed different
ways. Typical examples are shown in the
installation instruction:
A3 – Back wall installation with adjusta-
ble mounting studs.
B3 – Back wall installation.
C3 – Front wall installation.
D3 – Installation with installation sys-
tems.
Flushing of piping
system
According to DIN EN 1717 to complete
the installation it is necessary to flush
out both hot and cold water supply. The
tubes on the flush body are showing,
which inlet is connected with which
outlet. If only one outlet is in use, after
first flushing the flush body must turned
on 90°.
WARNING
Drain system completely if danger
of frost.

Technical Data

Operating pressure:
Recommended operating
pressure:
Hot water temperature:
Recommended hot water
temp.:
Centre distance:
Connections:
The used symbols:
Hot water
English
max. 1 MPa
0,1 – 0,5 MPa
max. 80°C
65°C
G1/2
hot left, cold right
Shut off
Cold water
valve
