Technical Data
200
380
485
380
Fig. 7-5
7-6
200
∅ 9
Brake resistor for
100 kW; 4 Ω
100 kW; 6.2 Ω
100 kW; 8.9 Ω
Mounting diagram, brake resistor
Bremseinheit / Braking Unit
710
740
Stud terminals, M6
Box dimensions: 760 x 500 x 320
Type
6SE7031-6ES87-2DC0
6SE7031-3FS87-2DC0
6SE7025-1HS87-2DC0
6SE7087-6CX87-2DA0
SIMOVERT MASTERDRIVES
03.2004
T1 / T2
Socket terminal
2
2.5 mm
Pg11
Pg21
M8
Weight, approx.
47 kg
43 kg
45 kg
