Operation

a) Tuning the wireless flush-mounted switch to a radio transmitter
The radio flush-mounted switch can be programmed to any radio transmitter of the RSL sys-
tem, e.g. to a radio-controlled wall transmitter or a wireless remote control.
The switch can be programmed to a total of 10 different radio transmitters of the RSL
system. Thus, the wireless flush-mounted switch can e. g. be switched on or off from
several locations.
Proceed as follows:
• Press and hold the push-button on the wireless flush-mounted switch (longer than 3 seconds)
until the LED next to the push-button starts to blink. The programming mode will be activated
for approx. 15 seconds and then exited automatically.
• When the programming mode is activated (LED next to the button flashes), press and hold
the "On" key of the radio-controlled wall transmitter ("I" key) or the corresponding "ON" key of
a wireless remote control (longer than 3 seconds) until the LED lights permanently and the
connected consumer load is turned on.
The tuning process has been completed successfully. The programming mode will be exited
automatically.
If you wish to tune the switch to another radio transmitter, the programming mode must be
activated first. Please proceed as described above.
The programming mode will also be activated (LED flashes) when the mains voltage
is connected (e. g. during initial start-up). Now a radio-controlled wall transmitter or a
wireless remote control can be programmed within approx. 15 seconds, see above.
b) Disabling a programmed, wireless flush-mounted switch from a radio
transmitter
If you wish to use the switching channel of a radio-controlled transmitter (radio wall switch or
wireless remote control) e. g. for another wireless flush-mounted switch, this channel can be
released as follows:
• For approx. 3 seconds, press and hold the two operating keys of your radio-controlled trans-
mitter for the "On" and "Off" function of the switching channel that you wish to release.
- Wireless wall switch: Press the "I" and "O" keys simultaneously for more than 3 seconds.
- Radio remote control: Press the "ON" and "OFF" keys simultaneously for more than 3
seconds.
• The LED on the wireless inbuilt switch starts blinking. The programming mode is now acti-
vated for approx. 15 seconds and afterwards, will be exited automatically.
• Press and hold the "O" key on a wireless wall switch or the "OFF" key of the corresponding
switching channel on a wireless remote control for at least 3 seconds.
• The LED on the wireless wall switch goes out.
• This disables the connection between the radio-controlled flush-mounted switch and the
radio-controlled transmitter. Now the radio-controlled inbuilt switch does no longer react to
the corresponding radio transmitter.
☞
Observe the operating instructions for the radio-controlled transmitter of the RSL
system you are using.
c) Switching on/off via the push-button on the wireless flush-mounted switch
For a function test the consumer load connected to the wireless inbuilt switch can also be
switched on and off using the push-button.
Briefly press the button on the wireless flush-mounted switch to turn the consumer load on
(LED on the switch lights up) or off (LED goes out).
Function test
• If haven't already programmed the wireless flush-mounted switch, you have to program or
tune it to a radio transmitter of the RSL system (e. g. to a radio-controlled wall switch or a
wireless remote control).
• Make sure that the wireless inbuilt switch is supplied with mains voltage (230 V/AC 50 Hz).
• Press the "I" button on the radio-controlled wall switch or the switching channel's "ON" button
of a radio remote control to which the wireless inbuilt switch was tuned.
The red LED on the wireless flush-mounted switch lights up and the switching output will be
activated and a connected consumer load switched on.
• To deactivate the switching output and to switch off the consumer load, briefly press the "O"
button on the radio-controlled wall switch or the switching channel's "OFF" key of the a wire-
less remote control to which the inbuilt switch was tuned/programmed.
The red LED on the wireless inbuilt switch goes out.

Maintenance

The product does not require any maintenance and should never be opened or disassembled
for any reason. Repair or maintenance work must be carried out by a specialist.
All manuals and user guides at all-guides.com Information about the range
Depending on the radio transmitter of the RSL system used, the range is up to 70 m.
The range can sometimes be limited considerably by:
• Walls, reinforced concrete ceilings
• Coated/vapour-deposited, metallized insulating glass panes
• Proximity to metal & conducting objects (e.g. radiators)
• Proximity to human bodies
• Broadband interferences, e.g. in residential areas (DECT telephones, mobile phones, radio-
• Proximity to electric motors, transformers, power-supply units, computers
• The proximity to improperly shielded or uncovered operating computers or other electric ap-
Declaration of Conformity (DOC)
We, Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau, hereby declare that
this product conforms to the fundamental requirements and the other relevant regulations of
the directive 1999/5/EC.
Disposal
Technical data
Operating voltage .........................230 V/AC, 50 Hz
Switching capacity ........................ 2000 W (resistive load)
Reception frequency .....................433 MHz
Transmission range ......................max. 70 m (see chapter "Range")
Ambient temperature ....................0 °C to +35 °C
Dimensions (H x W x D) ...............48.5 x 48.5 x 25 mm
Weight ..........................................approx. 39 g
This value, however, is the so-called "open space range" (the range the transmitter
and receiver are visible to each other, without disturbing influences).
In practical operation, however, there are walls, the ceilings of rooms etc. between
the transmitter and the receiver which reduce the range correspondingly.
Due to the different influences on the radio transmission, no specific range can
be guaranteed. However, trouble-free operation is usually possible in a detached
house.
controlled headphones, radio-controlled speakers, radio-controlled weather stations, baby
phones etc.)
pliances
The Declaration of Conformity for this product can be found at www.conrad.com.
Dispose of an unserviceable product in accordance with the relevant statutory regu-
lations.
300 W (inductive load)
Consumer loads with mainly resistive load are e.g. light bulbs, heaters etc.
Devices with inductive load are e.g. engines, control gears, conventional transform-
ers, energy saving light sources etc.
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau
(www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming,
or the capture in electronic data processing systems require the prior written approval by the editor.
Reprinting, also in part, is prohibited. This publication represent the technical status at the time of
printing.
© Copyright 2015 by Conrad Electronic SE.
