Digitaler Input; Zentral-Controller: Licht, Jalousien & Temp - ABB i-bus KNX Produkthandbuch

®

i-bus KNX EG/A 32.2.1
Temperatur
Status_ Setpoint
Status_ Temperature
Alarm
Status_ Alarm State
Fehler Status_ Error code
Status_ Window Contact
Fenster
Status_ Window Contact
Status_ External disablement
Externe
Status_ External disablement
Status_ Disable Remote Control
Sperren
Status_ Disable Remote Control
FUNKTION NAME
Alarm Status_Low Batery Alarm
Input
Status_ Input State
FUNKTION NAME
Status_ Daylight Harvesting
Licht
Status_ Dimming Level
ABB STOTZ-KONTAKT GmbH
Eppelheimer Straße 82, 69123 Heidelberg, Germany
 +49 (0) 6221 701 607  +49 (0) 6221 701 724
2 bytes DPT_Value_Temp 9.001
2 bytes DPT_Value_Temp 9.001
1 bit DPT_Alarm 1.005
2 bytes DPT_Value_2_Ucount 7.001
1 bit DPT_OpenClose 1.009
1 bit DPT_Window_Door 1.019
1 bit DPT_Bool 1.002
1 bit DPT_Enable 1.003
1 bit DPT_Bool 1.002
1 bit DPT_Enable 1.003
DATENPUNKTTYP
LÄNGE
DPT_NAME
1 bit DPT_Alarm
1 bit DPT_OpenClose
DATENPUNKTTYP
LÄNGE
DPT_NAME
1 bit DPT_Enable
1 byte DPT_Scaling
R T (ºC)
R T (ºC)
R T 0 – No alarm; 1 - Alarm
R T AC error (0 - no error)
R T 0 - Open; 1 - Closed
R T 0 - Closed; 1 - Open
R T 0 - False; 1 - True
R T 0 - Disable; 1 - Enable
R T 0 - False; 1 - True
R T 0 - Disable; 1 – Enable
FLAGGEN
DPT_ID R W T U
1.005 R T 0 – No alarm; 1 - Alarm
1.009 R T 0 – Open; 1 – Close
FLAGGEN
DPT_ID R W T U
1.003 R T 0 – Disable; 1 – Enable
5.001 R T %
