LECTUS duo 3000 readers
Pin
ID
4
D1
5
Tamper
6
Green LED
7
Red LED
8
Buzzer CTL
9
RS-485+/A
10
RS-485-/B
1
*
Wiegand interface
- maximum cable length 150 m
- minimum of 18 AWG (recommended)
2
*
RS485 interface:
- maximum cable length 1200 m
Notice!
i
Independent of using Wiegand or RS485, make sure that the
cables have a sufficiently large cross section and that the
cable shield is correctly connected.
Bosch Security Systems B.V.
Function
Data 0
Tamper
protection output
Green LED input
Red LED input
Beeper input
Data RxTx+
Data RxTx-
Connection | en
1
Wiegand*
RS485*
X
X
X
X
X
2020-10 | V02 |
29
2
X
X
