ENGLISH
Replacement of the connection cable
• The replacement of the connection cable
requires the specific equipment of a
technician. Only an original spare part
able must be used, provided by spare
parts service. The plug has to be fitted in

Product description

Cooking surface layout
120/180 mm
1
145 mm
2
3
a proper socket. If connecting the
appliance directly to the electric system,
it is necessary that you install a double
pole switch between the appliance and
the electricity supply, with a minimum
gap of 3 mm. between the switch
contacts and of a type suitable for the
required load in compliance with the
1
current rules.
• The connection cable has to be placed in
order that, in each part, it cannot reach a
temperature 70 °C higher than the room
2
temperature. The brown (or black) phase
cable (fitted in the terminal block contact
marked with "L") must always be
connected to the network phase.
Warning! Once connected to the
mains supply check that all
cooking zones are ready for use
by briefly setting each to
maximum power.
Double ring cooking zone 700 / 1700
1
W
Single cooking zone 1200 W
2
Control panel
3
10
