Read the safety and operating instruc-
tions carefully before you use your
heater for the first time. Material and
features have been selected to rule out
malfunctions provided the heater is
used as intended. Check that all parts
are complete. Caution: Use only
outdoors or in well-ventilated areas!
1. Description
The party heater is used outdoors to heat nearby
areas. A burner inside the perforated plate body
produces the necessary heat, which is radiated to
the immediate surroundings by an aluminium
reflector as well as by the perforated plate itself.
The party heater has to be set up on a level,
incombustible surface with no - or only a very slight -
gradient. Its center of gravity can be lowered
considerably by filling sand in the foot.
To make it easier to change the gas bottle, the body
can be raised and locked in place on the appliance
itself.
The party heater is designed to work only with
propane-butane (liquefied gas). It is connected
directly to the gas bottle by means of a DVGW-tested
and approved hose pipe and a liquefied gas
regulator (outlet pressure 28-30/37 mbar, capacity
1,5 kg/h). The following regulations have to
be observed and adhered to when making the
connection:
Technical regulations concerning liquefied gas
(e.g. TRF)
Guidelines published by liability insurance
associations concerning the use of liquefied gas
in special applications

2. Technical data

Dimensions Overall height:
Reflector diameter:
Power rating: 12 kW (Hi) / 13 kW (Hs)
Consumption: approx. 0,946 kg/h
Fuel: Propane/butane liquefied gas
Ignition: Piezo igniter
Monitoring: Thermoelectric flame monitor
Gas supply Gas bottles up to 11 kg
17.01.2006 13:18 Uhr

3. Items supplied

3.1 PS 12
Item 1 Reflector
Item 2 Burner, complete
Item 4 Column
Item 5 Container cover
Item 6 Container jacket
Item 7 Bulkhead
Item 8 Foot
Item 9 Foot base
Item 10 Allen screw size M 5 x 12
Item 11 Allen screw size M 6 x 12
Item 12 Allen screw size M 8 x 45
Item 14 Hexagon nut size M 5
Item 15 Hexagon nut size M 6
Item 16 Stop nut size M 8
Item 17 Washer size DM 5.3
Item 18 Washer size DM 6.4
Item 19 Washer size DM 6.4 large
Item 20 Washer size DM 8.4
Item 21 Wheels
3.2 PS 12 Niro
Item 1Reflector
Item 2 Burner, complete
Item 4 Column
Item 5 Washer
Item 6 Container cover
Item 7 Container jacket
Item 8 Bulkhead
Item 9 Foot
Item 10 Foot base
Item 11 Allen screw size M 5 x 12
Item 12 Allen screw size M 6 x 12
Item 13 Allen screw size M 8 x 45
Item 14 Raised cheesehead screw size
M 8 x 20
Item 16 Hexagon nut size M 5
Item 17 Hexagon nut size M 6
Item 18 Hexagon nut size M 8
Item 19 Stop nut size M 8
Item 20 Washer size DM 5.3
Item 21 Washer size DM 6.4
2300 mm
Item 22 Washer size DM 6.4, large
780 mm
Item 23 Washer size DM 8.4
Item 24 Wheels
Item 25 Edge strip size 360
Item 26 Edge strip size 245
You will need the following additional tools for the
installation:
1 wrench SW 8, SW 10, SW 14, SW 17
1 Phillips screwdriver
Seite 9
GB
1 piece
1 piece
1 piece
1 piece
1 piece
1 piece
1 piece
1 piece
8 piece
10 piece
2 piece
8 piece
4 piece
2 piece
8 piece
9 piece
1 piece
2 piece
2 piece
1 piece
1 piece
1 piece
1 piece
1 piece
1 piece
1 piece
1 piece
1 piece
8 piece
10 piece
2 piece
3 piece
8 piece
4 piece
3 piece
2 piece
8 piece
9 piece
1 piece
2 piece
2 piece
1 piece
3 piece
