4. Assembly (Fig. 1)
Important: The item numbers in the text refer to the
item numbers in sections 3.1 or 3.2
4.1 PS 12
1. Fit the wheels (21) to the foot base (9) with two
Allen screws (12), two washers (20) and stop
nuts (16). (Detail in Fig. A)
2. Screw the foot base (9) to the foot (8) with one
Allen screw (11), corresponding washer (19) and
one hexagon nut (15). (Detail in Fig. B)
3. Screw the container jacket (6) to the foot (8) with
four Allen screws (10) and corresponding
washers (17) and hexagon nuts (14).
(Detail in Fig. C)
4. Place the container cover (5) on the container
jacket (6) and screw together with four Allen
screws (10) and corresponding washers (17) and
hexagon nuts (14). (Detail in Fig. D)
5. Feed the hose through the column (4) and screw
the complete burner into the top of the column
(4) using 3 hex screws (11) and the corres-
ponding washers (18) (detail in Fig. E)
6. Place the column (4) on the container cover (5)
and screw tightly together with three Allen
screws (11) and corresponding washers (18) and
three hexagon nuts (15). (Detail in Fig. F)
7. Screw the reflector (1) to the burner (2) with
three Allen screws (11) and corresponding
washers (18). (Detail in Fig. G)
8. Fit the bulkhead (7).
9. Attach to gas cylinder as described in section 6.
4.2 PS 12 Niro
Take particular care when assembling sharp-
edged parts!
1. Fit the wheels (24) to the foot base (10) with two
Allen screws (13), two washers (23) and stop
nuts (19). (Detail in Fig. A)
2. Screw the foot base (10) to the foot (9) with one
Allen screw (12), corresponding washer (22) and
one hexagon nut (17). (Detail in Fig. B)
10
17.01.2006 13:18 Uhr Seite 10
3. Screw the container jacket (7) to the foot (9) with
four Allen screws (11) and corresponding
washers(20) and hexagon nuts (16).
(Detail in Fig. C)
4. Screw the washer (5) to the container cover (6)
from below with three raised cheesehead screws
(14) and corresponding hexagon nuts (18).
(Detail in Fig. D)
5. Place the container cover (6) on the container
jacket (7) and screw together with four Allen
screws (11) and corresponding washers (20) and
hexagon nuts (16). (Detail in Fig. E)
6. Feed the hose through the column (4) and screw
the complete burner into the top of the column
(4) using 3 hex screws (12) and the corres-
ponding washers (21) (detail in Fig. F)
7. Fit the column (4) to the container cover (6) and
screw together firmly with three Allen screws (12)
and corresponding washers (21) and three
hexagon nuts (17). (Detail in Fig. G)
8. Screw the reflector (1) to the burner (2) with
three Allen screws (12) and corresponding
washers (21). (Detail in Fig. H)
9. Fit the bulkhead (8).
10. Fit the edge strips to the bulkhead (8) and the
container jacket (7).
11. Attach to gas cylinder as described in section 6.

5. Safety instructions

This device must be installed as per the
applicable regulations.
Protect liquid gas cylinders from direct sunlight.
Set up the party heater on a level surface with
either no or only a very slight gradient (max. 5°).
Caution: The heater may be used only under
supervision.
Do not touch the reflector or perforated plate
when in use - Risk of burns!
Keep a safe distance between the heater and
combustible objects during use.
Do not fasten any objects to the party heater.
This device should only be used outdoors or the
site must have a volume of at least 20 m
kW of installed nominal heat load of the radiator
and there must be adequate ventilation.
3 per 1
