Seite 3
detection distance (detector height 1m) IR position standard (m) real, based on the thermal conditions of the environment 12,0 10,0 ... 15,0 6,0 ... 10,0 4,0 ... 6,0 4,0 ... 6,0...
Seite 4
top view 3° 3° side view (A position) side view (B position) side view (C position) side view (D position)
Seite 5
Optional • Optional • Optioneel • En option • Opzionale • Opcional...
Seite 7
Switch Werte Funktion Test modus. OFF (*) Normaler Betrieb. Battery saving: Verhinderung: Für jeden Zeitraum von 5 Sekunden wird nur ein Alarm erzeugt, auch wenn es mehrere Erfassungen gab (die Haltbarkeit der Batterie wird verringert). OFF (*) Idem, aber für 120 Sekunden. Zustands-LED aktiv (sie leuchtet bei normalem Betrieb bei jeder Erfassung auf).
Seite 8
Switch Waarden Functie Test modus. OFF (*) Normale werking. Battery saving: Uitsluiting: er wordt slechts één alarm gegenereerd voor elke periode van 5 seconden, zelfs als er meerdere detecties zijn geweest (de levensduurvan de batterij wordt verkort). OFF (*) Hetzelfde, maar met een periode van 120 seconden. Status-LED actief (licht op bij elke detectie tijdens normale werking).
Seite 16
ETSI 300 220 EN 50131-1 EN 50131-5-3 Hereby, manufacturer, declares that the radio equipment type “SMD-W4.1A”, “2CSYD0202B”, is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://new.abb.com/low-voltage/products/building-automation/product-range/intrusion-alarm-...
