Names Of Parts (See Fold-Out Page); Technical Data; Safety Information; Terms Used - Silvercrest SHLF 2000 A1 Bedienungsanleitung

RP74284 HL mit FB LB3 Seite 4 Freitag, 25. Mai 2012 3:18 15
1 Warning symbol - "Do not cover"
2 Control panel
3 Air outlet
4 Compartment for remote control
5 Handle
6 Air inlet
7 Temperature sensor
Mains switch
8
Base
9
10 Display
11 Function selector
12 Increase temperature
13 Reduce temperature
Power supply:
Output:
Protection class:
Battery for remote control:
Ambient conditions:

4.1 Terms used

The following signalling terms are found in
these Operating Instructions:
Warning!
High risk. Disregarding the warning
may cause injury to life and limb.
Caution!
Medium risk. Disregarding the warning may
cause damage to property.
Note:
Low risk. Circumstances that should be taken
into account when
appliance.
4
2. Names of parts
14 Infrared receiver
15 Increase minutes
16 Increase hours
17 Swivel function
18 Indicator light
19 Remote control
20 Increase temperature
21 Swivel function
22 Reduce temperature
23 Function selector
24 Increase minutes
25 Increase hours

3. Technical data

220 - 240 V~/50 Hz
1,000/2,000 watts
II
CR2032/3 V
0 °C to +40 °C, max. 85 % relative humidity

4. Safety information

4.2 General information

• Before using the appliance, be sure to
• Use the appliance only for the purpose
• Check whether the mains voltage (see
dealing with this
• This device is not intended to be used by
(see fold-out page)
read these Operating Instructions carefully.
They are a component part of the
appliance and must be available at all
times.
described (see "1.1 Intended purpose" on
page 3).
type plate on the appliance) agrees with
your mains voltage.
individuals (including children) with
