Sound pressure level L
pA
Sound power level L
WA

6. Before using for the first time

The machine must be set up so that it stands
firmly, i.e. it must be securely screwed to a work
bench, the base frame supplied in delivery, or
similar.
All covers and safety devices must be correctly
attached before the machine is used for the first
time.
The cutting wheel must rotate smoothly.
Check that the voltage on the rating plate is the
same as your supply voltage before you connect
the machine to the power supply.
7. RCD plug (Fig. 16)
Connect the RCD plug (41) to the power supply.
Press the reset button (42) and the control lamp (43)
will begin to shine. Press the test button (44) to
check the function of the RCD plug. If everything is
working properly the control lamp (43) will go out and
the contact to the power supply will be interrupted.
The RCD plug triggers at a fault current of 30 mA.
Defective RCD plugs must be replaced by a qualified
electrician.
Press the reset key (42) again in order to be able to
start up the machine.
8. Assembly and operation (Fig. 3/4/5)
8.1 Fitting the hose and cable guide (Fig. 17)
8.2 Assembly of the sub-frame and cooling water
pump (Fig. 2-4)
Secure the feet (1) to the water trough using the
thumb screws (12).
Place the complete tile cutter into the trough (3).
Place the cooling water pump (13) in a suitable
position in the water trough and secure it to the
base of the trough with the suction cups. The
pump, cable and cooling water hose (14) must
not be able to get into the cutting area.
Fill with water until the pump (13) is completely
immersed in water.
Remove the star handle screw (11) and spacer
(40).
02.10.2007 8:53 Uhr
Important: Before you lift the machine out of the
No-Load operation
trough or transport it, the cutting unit must be
94,5 dB
secured again with the star handle screw (11) and
107,5 dB
spacer (40).
8.3 ON/OFF switch (Fig. 6)
To switch on, press the "1" on the ON/OFF
switch (16).
Before you begin cutting, wait until the cutting
wheel has reached maximum speed and the
cooling water pump (13) has started supplying
the cutting wheel with water.
To switch off, press the "0" on the switch (16).
8.4 90° Cutting (Fig. 7/8)
Loosen the star grip screw (27).
Set the angle stop (5) to 90° and retighten the
star grip screw (27).
Retighten the screws (28) to fasten the angle
stop (5).
Move the machine head (29) to the far end with
the handle (9).
Position the tile against the rail fence (6) on the
angle stop (5).
Switch on the tile cutting machine.
Caution: Always wait until the cooling water has
reached the cutting wheel (2) first.
Move the machine head (29) slowly and
smoothly forward through the tile with the handle
(9).
Switch off the tile cutting machine after
completion of cutting.
8.5 45° Diagonal cut (Fig. 9)
Set the angle stop (5) to 45°.
Cut as described in 8.4
8.6 45° Lengthwise cut, "jolly cut" (Fig.10)
Loosen the star grip screw (10).
Tilt the guide rail (7) to the left to 45° on the
angle scale (17).
Retighten the star grip screw (10).
Cut as described in 8.4.
