Endress+Hauser Soliphant M FTM50 Sicherheitshinweise Seite 13

Soliphant M
Type of protection
EEx de IIC T3...T6 / EEx d IIC T3...T6
EEx de [ia] IIC T3...T6 / EEx d [ia] IIC T3...T6
EEx de [ia] IIC T6 / EEx d [ia] IIC T6
Please note the following installation instructions:
– Comply with the installation and safety instructions in the Operating Instructions.
– Install the device according to the manufacturer's instructions and any other valid standards and regulations
(e.g. IEC 60079-14).
– Pay attention to the maximum process conditions according to the manufacturer's Operating Instructions.
At high medium temperatures: note flange pressure load capacity as a factor of temperature.
– Connect the device using suitable cable and wire entries* or using piping systems of protection type
"Pressure-tight Enclosure (Ex d)".
* For selection criteria refer to EN 60079, Chapter 10.3.
– To maintain the ingress protection IP66/67 of the housing, install the housing cover and cable glands correctly.
Close unused entry glands with approved (Ex d) sealing plugs.
– Install the device to exclude any mechanical damage or friction during the application. Pay particular attention to flow
conditions and tank fittings.
– Support extension tube of Soliphant M FTM51 if a dynamic load is expected.
– Install the device to exclude impact and friction sparks on the aluminium housing.
– Only install the devices in media for which the wetted materials have sufficient durability;
e.g. process connection seal (see Technical Information TI 392F).
– Use a process connection seal that meets the materials compatibility and temperature requirements.
– When connecting the cables, ensure there is adequate strain relief at place of installation.
Assignment of the ambient and process temperatures to the temperature classes:
Type
FTM50, FTM51
FTM52
FTM50, FTM51
FTM50, FTM51
FTM50, FTM51
T
p
Endress+Hauser
for Soliphant M Type:
FTM50
FTM51
FTM52
Temperature class
T6
T5
T4
T3
T
a
70 °C
50 °C
–50 °C
–50 °C
Fluid temperature T
p (process)
(sensor)
–50 °C... +85 °C
–40 °C... +80 °C
–50 °C...+100 °C
–50 °C...+135 °C
–50 °C...+150 °C
T
a
0 °C
0 °C 50 °C
XA306F-A
Ambient temperature T
a (ambient)
(electronics)
–50 °C...+70 °C
see the temperature diagram below
100 °C 150 °C
90 °C
en
T
p
5
