SPECIFICATIONS
Frequency range:
FM; 87.5 - 108 MHz
.
Dimensions:
Width;
178 mm (7")
(50 kHz span)
Height; 50 mm (2")
MW; 522 - 1,620 kHz
Depth; 155.5 mm (6-1/8")
(9 kHz span)
|
(installation mount)
LW; 144 - 290 kHz
Width; 182 mm (7-3/16")
(1 kHz span)
Height; 53 mm (2-1/16")
Power source:
DC 12V
Depth; 160 mm (6-5/16")
(for negative earth car only)
Weight:
1.4 kg (3.1 Ibs.)
Output power:
MAX; 25 W + 25 W
RMS; 18 W + 18 W
(DIN 45 324)
Output impedance: 4 ohms (each)
NAMES OF PARTS
~~
. Bass Control
- Treble Control
. Station Preset Buttons: (1 - 6)
. Cassette Eject Button: ~
. Cassette Compartment
. Fast Wind/Programme Buttons:
<< PROG PP
. Handle
. Front/Rear Fader Control
. Power On-Off/Volume/Balance Control
10. FM Mono-Stereo Selector Button
11. DX-Local Selector Button
12. ASPM/Preset Memory Scan Button
13. Band Selector Button
|
14. Tuning Up Button
9
1011
12 13
14 15 1617
18
15. Tuning Down Button
16. Seek Tuning Button
17. SDK Button
18. CD Input Socket
19. Radio Band Indicators
20. SDK Indicator
21. SK Indicator
22. Station Preset Memory Indicator: CH
23. Local Indicator: LOC
24. FMStereo Indicator: ST
25. Radio Frequency
26. Station Preset Number
27. Tape Direction Indicators: </>
OOnN
AA
hdAN
—
19
20
2122 23 24
=
tis [Loe st
1GEhe
ie
ey T
_————
Se
25
26
27
