Product Description and Specifications
Please observe the illustrations at the beginning of this operating manual.
Intended Use
The measuring tool is intended for determining and checking horizontal and vertical lines
and plumb points.
The measuring tool is suitable for indoor use.
Product Features
The numbering of the product features shown refers to the illustration of the measuring
tool on the graphic page.
(1) Button for laser operating mode Mode
(2) Incline function button
(3) Status indicator
(4) On/off switch
(5) Magnet (internal)
(6) Laser beam outlet aperture
A)
(7) Tripod
(8) Laser viewing glasses
(9) 1/4" tripod mount
(10) Battery compartment cover locking mechanism
(11) Battery compartment cover
(12) Laser warning label
(13) Serial number
A) Accessories shown or described are not included with the product as standard. You can
find the complete selection of accessories in our accessories range.
Technical Data
Cross line laser
Article number
Working range (diameter) up to approx.
Aperture angle for vertical laser lines
Bosch Power Tools
A)
A)
English | 17
AdvancedLevel 360
3 603 F63 B..
24 m
120°
