English
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved
by a person responsible for their safety. Children shall not play
with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
Electricity safety
• Do not use a damaged power plug or loose
electrical outlet.
• Do not move the product by pulling the power
cord.
• To prevent the power cord from being damaged
or deformed, do not forcibly bend it or run it
under a heavy object.
• If the electrical outlet is wet, carefully unplug
the product and allow the electrical outlet to
completely dry before subsequent use.
• Do not handle the power plug with a wet hand.
• Do not plug in and unplug the power plug
repeatedly.
• Unplug the product before inspection or parts
replacement.
• Remove any dust or water from the power plug.
• Unplug the product if it is not to be used for a
long time.
• If the power cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
• Do not attempt to repair or modify the power
cord.
• This product shall only be used together with the
included power supply unit.
• If any part is damaged, the product should not be
used.
Installation safety
• The product is only intended for household use
under normal operating conditions.
• Do not install the air purifier near a heating
device.
• Do not use the product in wet environments or
in environments with high humidity, such as the
bathroom or in a room with great variations in
temperature.
• Leave at least 30 cm of free space around the
product.
• Do not use the product in areas where flammable
gases or combustible materials are used or
stored.
• Do not exert excessive force or subject the product
to bumps and bangs.
• Install the product so that no obstacles around the
product block the circulation of air.
Operation safety
Never place the product in water.
• Do not disassemble, repair or modify the product.
• Unplug the product before you clean it.
• If the air purifier produces a strange noise,
burning smell or smoke, immediately remove the
power plug from the electrical outlet and call our
Customer support.
• Do not spray any flammable materials into the air
inlet.
• Do not stick fingers or foreign objects into the air
inlet or outlet.
• Replace the filter with a new one according to
filter replacement cycles. Product performance
may otherwise deteriorate.
• Do not push or lean against this product since it
may tip over and cause physical injury or product
malfunction.
Care Instructions
Unplug the product before cleaning.
To clean the product, wipe with a soft moistened
cloth. Use another soft, dry cloth to wipe dry.
Vacuum-clean the pre-filter regularly.
Note!
Never use abrasive cleaners or chemical solvents as
this can damage the product.
Fan speed control
The fan can be set to 3 different speeds by pressing
the power button multiple times.
A long press will turn the air purifier OFF regardless
of current speed level.
The LED lamp's brightness indicates the chosen
speed level.
1x
2x
Filter replacement
When replacing the filter, it is essential that the user
proceeds as follows:
A LED light on the control
panel indicates when you
should check your filters.
Warning!
The power supply cord must be disconnected
during filter replacement!
1. Disconnect the power and wait until the fan has
stopped.
2. Remove the pre-filter by the finger indent. Clean
the pre-filter with a vacuum cleaner or with
water depending on how dirty it is.
3. Remove the particle filter and handle the used
filter carefully, dispose of the filter in accordance
with local environmental regulations in your
country.
4. Clean inside, removing all dust and dirt.
5. Reconnect the power supply cord.
6. Press and hold the RESET button for 3 seconds.
The reset initialises the filter replacement cycle
counter.
7. Insert the new particle filter.
8. Fix the pre-filter in place.
• Wash your hands thoroughly after replacing the
filter.
Filter cleaning and replacement cycles
Filter
Pre-filter
Particle filter
* The recommended filter replacement cycles may
differ depending on the operating environment.
Run modes with filter for particle removal.
Level
I
31 dB(A)
II
47 dB(A)
III
55 dB(A)
Save these instructions for future use.
Technical specifications
Model: UPPÅTVIND air purifier
Type: E2111
Input: 24.0V DC, 0.8 A, 19.0W
Dimensions: 280 x 225 x 125 mm (HxWxD)
Weight: 1.6 kg
Filter: Filter for particle removal.
• Operational temperature: 10°C to 40°C.
3x
• Humidity when operational: 10-60% RH
(Recommended operational humidity: 40-60% RH)
Technical data PSU
Type: ICPSW24-19-1
ICPSW24-19-1A
Input: 100-240 VAC, 50/60 Hz, 0.4A
Output: 24.0V DC, 0.8 A, Max 19.0W
Average active efficiency: 88.6 %
Efficiency at low load (10 %): 82.3 %
No load power consumption: 0.073 W
Indoor use only
Manufacturer: IKEA of Sweden AB
(commercial registration number: 556074-7551)
Address: Box 702, SE-343 81 Älmhult, SWEDEN
The crossed-out wheeled bin symbol indicates that
the item should be disposed of separately from
household waste. The item should be handed in for
recycling in accordance with local environmental
regulations for waste disposal. By separating a
marked item from household waste, you will help
reduce the volume of waste sent to incinerators or
land-fill and minimize any potential negative impact
on human health and the environment. For more
information, please contact your IKEA store.
cycles
method
Every 2~4
Cleaning
weeks
Every 6
Replacement
months
Noise
CADR
Power
(Spl)
31 m³/h
2.4 W
60 m³/h
4.5 W
95 m³/h
8.0 W
4
